General
1.) Select a language using the
initialization has been concluded, you CANNOT change the selected language anymore (except if
you reset the system).
2.) Press the
asked to press the [OK] button.
3.) Press . Now you will be asked to press the [ESC] button.
4.) Now press
5.) You now have 2 possibilities:
A) Initialization after having replaced the control panel
If it was necessary to replace the control panel because it was defective, then fingers had
already been recorded in the ekey home finger scanner. In order not to have them deleted, a
pre-recorded finger may now be swiped over the sensor, and the initialization process is
started without deleting any data.
B) New installation
If this is a new system (new installation), press the
The system now initializes. All the fingers recorded previously on the finger scanner will be
deleted.
6.) "Initializing OK " is then displayed for 1-5s. The control panel and the finger scanner have now
been coupled.
7.) Now the 14-digit serial number and the 4-digit software version number of the ekey home CP DRM
and of the ekey home FS (finger scanner) are displayed. The initialization procedure has now been
concluded.
System OK:
means that the
communication
connection
between the ekey
home FS and the
ekey home CP
DRM is working
properly.
© ekey biometric systems GmbH
buttons. It is now that you must define the language! After the
button. A time counter is displayed, which counts from 45 seconds to 0. You will be
.
Operating instructions ekey home
button once again.
Number of fingers which can still be enrolled
ekey home CP DRM serial number
ekey home CP DRM software version
ekey home FS serial number
ekey home FS software version
