General
2.) Press the > button until "Sc" is displayed
3.) Press the OK button
4.) Enter the left digit of the new security code using the < and > buttons
5.) Press the OK button
6.) Enter the right digit of the new security code using the < and > buttons
7.) Press the OK button
8.) "OK" is displayed for a short time. The device then returns to normal mode
9.) Memorize your security code, or write it down and keep it in a safe place, separately from the ekey
home control panel.
8.2.1.10 ACCESSING SERIAL NUMBER AND VERSION NUMBER
The serial number and the version number of the components of your ekey home system,
ekey home CP and
ekey home FS
can also be accessed via the 7-segment display. Two digits of the number are displayed at a time. This is
especially important for integra models, as their parts are built-in and the labels are usually hardly or no
longer visible.
The serial number corresponds to the serial number of the device and therefore allows you to determine
the date of production and the hardware model. The version number corresponds to the update version of
the software. You will only need both these numbers if you are in contact with our technical support team
in order to solve a problem you are facing.
8.1.1.10.1 ACCESSING THE SERIAL NUMBER
1.) First enter the security code as per section 8.2.1.6
2.) Press the > button, until "In" is displayed
3.) Press the OK button
4.) Use the < and > buttons to select the option „Sn" for serial number
5.) Press the OK button
6.) Use the < and > buttons, to select which device you wish to view the serial number of:
"FS".... Finger Scanner
"CU".... Control Panel
7.) Press the OK button
8.) Now you will be able to see the first two digits of the serial number. By pressing the > button you
can view the remaining digits. The serial number is 14 digits long.
9.) By pressing the OK button you return to the first two digits of the serial number. If you press the
ESC button once you have reached the last two digits the display moves up a level in the
navigation.
8.1.1.10.2 ACCESSING THE VERSION NUMBER
1.) First enter the security code as per section 8.2.1.6
2.) Press the > button, until "In" is displayed
3.) Press the OK button
4.) Use the < and > buttons to select the option „US" for version number
5.) Press the OK button
6.) Use the < and > buttons, to select which device you wish to view the version number of:
"FS".... Finger Scanner
"CP".... Control Panel
7.) Press the OK button
8.) Now you will be able to see the first two digits of the version number. By pressing the > button
you can view the remaining digits. The serial number is 8 digits long.
By pressing the OK button you return to the first two digits of the version number.
If you press the ESC button once you have reached the last two digits the display
moves up a level in the navigation.
© ekey biometric systems GmbH Operating instructions ekey home Page 21 / 41
