eKey Fingerscan Access Control System Operating Instructions Manual page 29

General
1.) First, enter the security code as per section 8.2.2.4
2.) Select "Enroll user" in the main menu.
3.) Press the
4.) Select the user: This is what the user / finger matrix looks like:
User number
Each individual user is indexed through the user number. On the right hand side, beside the user
number, you can check if any finger has been saved for this one user. The numbers 1, 2 or D
indicate
that for this user, this one finger has been allocated
which relay switches for this finger and
via the location of the dash which finger this is.
_ _ _ _ _ _ _ _ _
1 2 7
Begin counting with the little finger on the left hand. In the example above, finger #7 has been
already enrolled. If you use our finger counting method, then finger #7 is the right index finger.
Select the desired user number for which you wish to enroll a finger using the
5.) Press the
6.) Set the user name
Navigate with the
You can now use set each letter of the user name by using the
button to save the setting and go to the next menu item. You can thus define a meaningful name
for each user.
Once you have confirmed the setting of the 9 letters of the user name by pressing
is the saved name for this user. In our example, the user is called "MUSTERMAN".
© ekey biometric systems GmbH
button.
1
5 6
10
button.
button to the user name and press the
Operating instructions ekey home
The numbers show that these fingers for the
corresponding user have already been allocated
and which relay switches for each finger:
1 ... Relay 1
2 ... Relay 2 (only for ekey home CP DRM 2)
D ... Double relay (only for ekey home CP DRM
2)
9
0
buttons.
button.
buttons. Press the
Page 29 / 41
, then this
