General
Enter security
STA RT
code
Enter security
code
The red dot only flashes if this memory space
has already been allocated (there already is a
user or a finger on this position)!
KEY DISPLAY
STROKE
1.) First, enter the security code as per section 8.2.1.6:
2.) When the display shows "Eu", press the OK button.
3.) Select the user: The display shows the number "1". If this user number is already in use, this is
signalized by a lighted dot next to the number. For example: „1.". Set the desired user number
using the < and > button.
4.) Press the OK button.
5.) Select the finger: On the display "F1" stands for finger 1 = small finger on the left hand. Please
begin counting with the little finger on the left hand.
The little finger on the right hand is number 10 (= setting "F0" on the display). If a finger number
has already been allocated, then this is also signalized with a dot next to the number. For example
set the index finger on the right hand as "F7". If the finger has already been recorded, then you
will see a flashing dot beside the finger number, e.g. „F1.". You may still record the finger however
if you wish to do so. The preceding finger will then be automatically overwritten.
6.) Press the OK button.
7.) Consider step 7 only if you have an ekey home control panel with more than 1 relay:
ekey home CP IN 2
ekey home CP WM 3
You can now determine which relay is meant to be controlled by the previously selected
fingerprint. "o1" on the display signalizes that at the moment the first relay (the motor lock) is
selected (standard setting).
"o1" ... Relay 1
"o2"...
"o3"... Relay 3
"od"...
finger swipe only. Both relays switch according to the set relay switching times (e.g. relay 1
3 seconds and relay 2 6 seconds).
Use the < and > buttons to select the relay to be controlled.
8.) Press the OK button.
© ekey biometric systems GmbH
DISPLAY KEY STROKE
DISPLAY
Swipe
USER
FINGER
Relay 2
Double relay function: Relay 1 and relay 2 switch simultaneously with one
Operating instructions ekey home
DISPLAY + KEY STROKE DISPLAY +
SETTING
Select USER Select FINGER
NUMBER NUMBER F1-
0-99
F10
DISPLAY DISPLAY
9
1
0
5 6
KEY STROKE DISPLAY +
SETTING SETTING
Select RELAY
o1-o3 or od
FINI SHED
User finger recorded
