Sun Oracle Netra T5220 Installation Manual page 37

You also need the hardmount brackets from the standard rackmount kit that came
with the server (
FIGURE 3-6
2
Figure Legend
1 Long brackets
2 Short brackets
3 Threaded strips
Sliding Rail 19-inch 4-Post Rackmount Screw Kit Contents
TABLE 3-3
Number Description
10 M4 x 0.5 mm x 5 mm Phillips panhead screws
10 M6 brass collar screws
8 M5 panhead screws, nuts, plain washers and
star washers
).
FIGURE 3-6
Contents of the Sliding Rail 19-Inch 4-Post Kit
4
3
1
4 Screws
5 Telco slide assemblies
6 Extension brackets
Where Used
8 for glides, 2 extra
4 for short brackets, 4 for long brackets, 2 extra
8 for slides
Chapter 3 Mounting the Server Into a 4-Post Rack
5
6
