The following example output is a small section of the complete output.
-> start /SYS
Find dropin, Copying Done, Size 0000.0000.0000.1110
Find dropin, (copied), Decompressing Done, Size
0000.0000.0006.06e0 cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu
cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu cpu
vpci mem32base, mem64base, cfgbase: e800000000 e000000000
e900000000
pci /pci@780: Device 0 pci pci
/pci@780/pci@0: Device 0 Nothing there
/pci@780/pci@0: Device 1 pci pci
....................
/pci@7c0/pci@0: Device a Nothing there
/pci@7c0/pci@0: Device b Nothing there
/pci@7c0/pci@0: Device c Nothing there
/pci@7c0/pci@0: Device d Nothing there
/pci@7c0/pci@0: Device e Nothing there
/pci@7c0/pci@0: Device f Nothing there
Probing I/O buses
Netra T5220, No Keyboard
...
{0} ok
To understand the various devices and their path names as represented in the
OpenBoot device tree, refer to
cards.
Device Identifiers and Devices
TABLE 6-1
Device Identifiers
/SYS/MB/CMPcpu-number/Pstrand-number
/SYS/MB/RISERriser-number/PCIEslot-number
/SYS/MB/RISERriser-number/XAUIcard-number
/SYS/MB/GBEcontroller-number
/SYS/MB/PCIE
/SYS/MB/USBnumber
for disks and
TABLE 6-1
Devices
CPU strand (Number: 0-63)
PCIe slot (Number: 0-5)
XAUI card (Number: 0-1)
GBE controllers (Number: 0-1)
• GBE0 controls NET0 and NET1
• GBE1 controls NET2 and NET3
PCIe root complex
USB ports (Number: 0-1, located on
rear of chassis)
Chapter 6
for optional PCI
TABLE 6-2
Powering On the System 93
