Sun Oracle Netra T5220 Installation Manual page 43

Two adjustable rails
■
Two side rails
■
Two rear flanges
■
Bag of screws
■
Note – The front-to-back rail spacing must be at least 392 mm (15.43 in.) and not
more than 504 mm (19.84 in.) from the outside face of the front rail to the outside
face of the back rail.
FIGURE 3-14
2
Figure Legend
1 Adjustable rails
2 Screws
Hardmount 600 mm 4-Post Rackmount Screw Kit Contents
TABLE 3-4
Number Description
12 M5 x 7 SEM screws
10 M5 x 12.7 mm screws
Contents of the Hardmount 600-mm 4-Post Kit
1
3
3 Side rails
4 Rear flanges
Where Used
8 for side rails, 4 for rear flanges
10 for rack, if appropriate
Chapter 3 Mounting the Server Into a 4-Post Rack
4
33
