Cabling the Server

This chapter provides instructions for cabling the server. Topics include:
"Cable Connections and Ports" on page 65
■
"Connecting the Server Cables" on page 69
■
"DC Operation Conditions and Procedures" on page 73
■
Note – Both AC and DC versions of the server must be installed in a restricted-
access location.
Caution – The Sun Netra T5220 must not be directly connected to Outside Plant
cables.

Cable Connections and Ports

The following list describes the server's cable connections and ports:
Minimum cable connections for the servers:
■
■
■
■
■
Service processor management ports: There are two serial management ports for
■
use with the ILOM system controller.
At least one system on-board Ethernet network connection (NET port)
The service processor serial management port (SER MGT port)
The service processor network management port (NET MGT port)
AC or DC power cables for the two system power supplies
