TABLE 1-1
Feature
Internal Hard Drives
Optical Media Drive
Power Supplies
Alarm
Cooling
Ethernet Ports
PCI Express Interfaces
USB Ports
Additional Ports
Remote Management
Firmware
Cryptography
6
Sun Netra T5220 Installation Guide • November 2011
Feature Specifications (Continued)
Description
Two hot-pluggable 146 GB SAS drives with a DVD-RW drive
Or
Four hot-pluggable 146 GB SAS drives without a DVD-RW drive
Integrated hard drive controller supports RAID 0 and RAID 1.
One, slot-loading, slimline DVD drive, supporting CD-R/W,
CD+R/W, DVD-R/W, DVD+R/W
Two hot-swappable 660W AC/DC power supply units (PSUs)
providing N+1 redundancy
One Telco alarm
Three high-power fans for processor, memory FB-DIMM, and
PCI card cooling
Three low-power fans for hard drive and removable media
drive cooling
Four 10/100/1000 Mbps Ethernet, RJ-45-based, autonegotiating
ports (on two separate controllers)
Note - Two 10 GbEports are available by adding XAUI cards
*
• One eight-lane PCIe slots
• Three four-lane PCIe slots
• Two PCI-X (one full-length and full-height, one half-
length/full-height) slots
Two USB 2.0 ports on rear panel
The following ports are located on the rear panel of the server:
• One RJ-45 serial management port (SER MGT) – the default
connection to system controller
• One 10/100 Mbps Ethernet network management port (NET
MGT) – connection to the system controller
• One Alarm port – connection to the alarm card
• One DB-9 serial port – connection to the host
On-board Integrated Lights Out Manager with two command
sets:
• ILOM CLI
• ALOM CMT compatibility CLI (legacy command set)
Firmware comprising:
• OpenBoot™ PROM for system settings and power-on self test
(POST) support
• ILOM for remote management
Processor integrated, cyptographic acceleration that supports
industry standard security ciphers
