Tip – The Sun Netra T5220 server mounted in a 2-post rack with the 19-inch, 2 post
mounting kit (X7901A-4) protrudes 193 millimeters (7.59 inches) beyond the front of
the rack rail post.
For less protrusion in the front of the rack, the server can also be mounted using the
rear portion of the rail, which reduces protrusion to 115 millimeters (4.52 inches)
beyond the front of the rack rail post.

2-Post Rackmounting Options

The server ships with a 19-inch, 4-post hardmount rack kit (see
Server in a 19-Inch 4-Post Rack" on page 22
lists two additional 2-post rackmount kit options that can be ordered from Sun. This
chapter provides installation instructions for these rackmount kit options.
TABLE 4-1
Mounting Kit
23-inch 2-post rackmount kit
19-inch 2-post rackmount kit
19-inch 2-post slide rackmount kit
Note – If you have more than six DC-powered servers in the same rack, you might
exceed Telcordia NEBS EMI limits.
42 Sun Netra T5220 Installation Guide • November 2011
Optional Rackmount Kits
for installation instructions).
Installation Instructions
"To Install a Server With a Hardmount in a 23-Inch 2-
Post Rack" on page 43
"To Install a Server With a Hardmount in a 19-Inch 2-
Post Rack" on page 48
"To Install a Server With a Sliding Rail Mount in a 19-
Inch 2-Post Rack" on page 54
"Hardmounting the
TABLE 4-1
