Sun Oracle Netra T5220 Installation Manual page 54

Figure Legend
1 Side brackets
2 Screws
Hardmount 23-Inch 2-Post Rackmount Screw Kit Contents
TABLE 4-2
Number Description
10 M5 x 7 SEM screws
10 M5 x 12.7 mm screws
10 M6 x 13 mm screws
9 M6 square clip nuts
12 10-32 x 0.5 in. combo head screws
12 12-24 x 0.5 in. combo head screws
1. Get the side brackets from the rack kit (
2. Using eight of the M5 × 7 SEM screws (four for each side bracket), secure the
side brackets to the sides of the server (
FIGURE 4-2
3. Get the rail guides from the rack kit (
44 Sun Netra T5220 Installation Guide • November 2011
Securing the Side Brackets to the Side of the Server
3 Rear plates
4 Rail guides
Where Used
8 for side brackets, 2 for rear plates
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
).
FIGURE 4-1
).
FIGURE 4-2
).
FIGURE 4-1
