Sun Fire X4270 M2 Server Components
TABLE 1-3
Component
CPU
Memory
Storage devices
USB ports
PCI Express 2.0 I/O slots
PCI Express I/O cards
Ethernet ports
Service processor (SP)
Power supplies
Cooling fans
Management software
12 Sun Fire X4170 M2 and X4270 M2 Servers Installation Guide • January 2012
Sun Fire X4270 M2 Server
One or two quad-core (2.4-GHz) or six-core (2.93-GHz or 3.33-GHz) processors
with three integrated DDR3 memory controllers per processor. The following
CPUs are supported:
• 130 Watts
• 95 Watts
• 80 Watts
Nine DDR3 DIMMs per processor for a maximum of 18 DDR3 DIMMs and a
maximum of 144 GB of memory
• Up to twelve 3.5-inch SAS/SATA HDDs with the optional Hardware RAID
controller
• Up to twenty-four 2.5-inch SAS/SATA HDDs with the optional Hardware RAID
controller
• Up to two optional rear-located (using PCIe slots 2 and 5) 2.5-inch SATA HDDs.
These disks are for boot purposes only.
Two front, two rear, and one internal (for a USB drive)
Six x8 low-profile PCIe Gen2 slots
For a list of I/O cards that are customer-orderable options, go to the following
web site and navigate to the appropriate page:
Four Gigabit Ethernet (GbE) ports on rear panel
Each Network Interface Card (NIC) supports I/O Acceleration Technology 3
(IOAT3)
Uses the SP subsystem
Includes the Baseboard Management Controller (BMC), which supports the
industry-standard IPMI feature set
Supports remote KVMS over IP
Includes a serial port
Supports Ethernet access to SP through a dedicated 10/100BaseT management
port and optionally through one of the host GbE ports (sideband management)
Up to two hot-pluggable power supplies
Redundant hot-pluggable fans
Oracle Integrated Lights Out Manager 3.0
