Sun Oracle Fire X4170 M2 Installation Manual page 16

(Continued)
Figure Legend
7 Hard disk drive 0 (optional)
8 Hard disk drive 3 (optional)
9 Hard disk drive 2 (optional)
The Sun Fire X4270 M2 Server can optionally be configured with 12 or 24 storage
drives.
storage drive configuration.
FIGURE 1-3
Figure Legend
1
2
3
4
5
6
7
8
9
10 Hard disk drive 4 (optional)
11 Hard disk drive 5 (optional)
Note – In
6 Sun Fire X4170 M2 and X4270 M2 Servers Installation Guide • January 2012
shows the 12 storage drive configuration.
FIGURE 1-3
Sun Fire X4270 M2 Server Front Panel (With 12 Storage Drives)
Product Serial Number (PSN) label and Radio
Frequency Identification (RFID) tag
Power button
Locator LED/Locator button: white
Service Action Required LED (System Level):
amber
Power/OK LED: green
Hard disk drive 2 (optional)
Hard disk drive 1 (optional)
Hard disk drive 0 (optional)
Hard disk drive 3 (optional)
, the storage drives are numbered 0 to 23 from left to right.
FIGURE 1-4
16 Disk configuration label
17 Power Supply Service Action Required LED:
amber
12 Hard disk drive 6 (optional)
13 Hard disk drive 7 (optional)
14 Hard disk drive 8 (optional)
15 Hard disk drive 9 (optional)
16 Hard disk drive 10 (optional)
17 Hard disk drive 11 (optional)
18 Fan Module Service Action Required LED:
amber
19 Power Supply Service Action Required LED:
amber
20 System Overtemperature LED: amber
21 USB 2.0 ports (2)
22 Disk configuration label
shows the 24
FIGURE 1-4
