4.5.2.1 Add Macro
To add a Macro, select the "Add Macro" button. The keyboard screen will appear allowing a
Macro name to be typed in. Choose a name that is meaningful. A name of up to 15 characters
will be displayed. The new Macro name will appear on the list and its "Actions" list will be
blank.
Touch the box under "Actions for <macro name>. Actions may now be added. Select "Add
After" to enter the first action. This will bring up the Automation Edit Action screen (for a
description of options available, see Figure 69, and text following it, above).
Continue to define the Macro script by adding Actions before or after existing Actions (highlight
existing actions using the front panel adjustment knob). Existing Actions may also be
highlighted and edited (select the "Edit" button) or removed (select the "Remove" button).
4.5.2.2 Delete Macro
To delete a macro, highlight it on the list and select the "Delete Macro" button.
Any actions contained in the Macro script must be removed before it can be deleted.
Highlight the actions on the list and select the "Remove" button.
Caution. A macro may be deleted even if it is associated with an Event and assigned to an
Automation button.
4.5.3 Automation Buttons
The Automation Buttons screen shows existing buttons assigned to an Event. Information on the
associated event appears below each configured button.
Menu (System) > Automation > Buttons
Figure 73. Automation Buttons
To configure a button, touch the button to select it.
A screen will open that allows both the button title and the event assignment to be configured.
