About AP20 Audio Processor
The AP20 audio processor has been engineered to deliver precise reproduction of both analog and digital
sources, using the power of 6 Analog Devices 400MHz DSPs. The standard AP20 offers 16 channels of
digital and 8 channels of analog inputs coupled to the 16 digital and 16 analog outputs. In addition to 1
S/PDIF and 2 TOSLINK inputs, the AP20 features 4 HDMI 1.3b inputs with Blu-Ray HD decoding and
active loudspeaker crossovers.
An 8 channel version of the AP20 is also available. Please see appendix G, in this manual, for
more information.
Each of the 16 channels include:
31 bands of 1/3 octave equalization
3 bands of parametric equalization
Channel gain & phase inversion control
Individual Bass & Treble controls
Variable delay line adjustable from 0ms to 1000ms
One of the most compelling features of the AP20 is the inclusion of Dirac Live
®
technology. Dirac Live
experience by correcting for room modes and anomalies using high-resolution filter technology.
Configure once and never touch again. The result - improved musical staging, clarity of dialogue and an
enhanced listener experience.
For even greater flexibility, the AP20 Audio Processor has three product expansion slots that are
removable from the back of the unit while racked. All internal control and data lines are available to
expansion cards to service future user needs.
To get the most out of your AP20, we suggest that you review this manual and keep it available during
system installation and initial operation.

Limited Warranty

Datasat Digital Entertainment software is warranted against defects for a period of 90 days from the date
of the original purchase. AP20 hardware is warranted against defects in material and workmanship for a
period of one year from the date of the original purchase. This warranty includes parts and labor.
THIS WARRANTY EXCLUDES UNITS THAT HAVE BEEN MODIFIED, REPAIRED BY
UNAUTHORIZED PERSONNEL, OR DAMAGED BY ABUSE, IMPROPER OPERATION, DIRT,
MOISTURE OR STATIC ELECTRICITY. PROPER OPERATION OF THIS EQUIPMENT
REQUIRES THE USE OF A SURGE PROTECTOR. SUPPLYING POWER TO THE AP20 UNIT
WITHOUT THE USE OF A PROPERLY FUNCTIONING SURGE PROTECTOR WILL VOID THIS
WARRANTY.
Using an uninterruptible power supply (UPS) is highly recommended.
Products being returned under warranty should be sent to Datasat Digital Entertainment freight prepaid
in the original or equivalent packaging. Please contact Datasat Digital Entertainment prior to shipping
any parts or merchandise to receive a Return Merchandise Authorization number. Datasat Digital
Entertainment's shipping address is:
AP20 Installation & Operating Guide
AP20 Installation and Operating Guide
is a state-of-the-art digital room correction technology that improves the listener
®
room optimization
Document # 9301H39200 Ver. 1.2
Page 7
