Signal Outputs
Digital Audio Outputs
Channels: 16 (fully routable as to input)
Connector: Two DB25 (Male) connectors (1-8) and (9-16)
Digital Format: AES/EBU
Sample Rates: 48kHz, 96 kHz and 192kHz
Analog Audio Outputs
Balanced (can be connected unbalanced or single ended)
- Channels: 16 (fully routable as to input), common mapping with Digital Outputs
- Connectors: Two DB25 (Male) (1-8) and (9-16)
- Level: -10dBu with Fader at 7, +26dBu max (balanced)
Connector: 1 single ended RCA output, channel-selectable to drive an external monitor.
Adjustable Levels, to 300mv rms
Connector: 1 single ended RCA output, summed output for the hearing impaired. - Fixed Level
Out, 300mv rms
Audio EQ
Dirac Live® Room Optimization
16-Channel Dirac Live® room optimization
Installer kit required to install Dirac Live®
3rd Octave EQ
16 channels - 31 user-adjustable bandpass filters
Adjustable in 0.5dB steps; total gain or loss of 6dB
Frequencies range from 20Hz to 20kHz.
Parametric
16 channels with 3 user-adjustable parametric filters for shaping Subwoofer response.
Adjustable from 20 to 200Hz, gain +/-6dB in 0.1dB steps
Q range from 0.7 to 5.
Hi/Low/Bandpass Active Crossovers
Adjustable from 20Hz to 20kHz; adjustable slope of 6, 12, 18 or 24dB per octave
Bass/Treble tone control
Adjustable +/-6dB at 150Hz and 5.5kHz
