Unpacking
The packaging is designed to handle normal shipping and handling. Upon receipt of shipment, check for
signs of damage before opening and report all damage to the carrier. All shipments made from DDE are
customer responsibility once they leave our premises.
Before installation begins, we suggest that a complete inventory be taken to minimize problems or
questions during installation. Additionally, save all packing material until installation is complete in the
unlikely event that a component(s) requires return to the factory. Use the packing slip that came with
your unit to verify received inventory.
The following is a standard packing list for the AP20 Audio Processor:
Table 1. AP20 Standard Packing Kit
ITEM KEY
2501000100
9003E11901
9003H40200
9306H40900
9306F42200
9331H39200
9303H41000
Table 2. 9003H40200 Hardware Kit, AP20 connector
ITEM KEY
2007000905
2007002510
2007002511
2022000100
2022000300
Caution Notices
Power Cord to the AP20 rear panel: The power cord is the main disconnect device. It should
be plugged into an easily accessible outlet with surge protection. The power cord is to be used in
a minimum type SVT 18/3 rated 250 Volts AC, 10 Amps with a maximum length of 4.5 M, with
one end terminated in an IEC 320 attachment plug and the other end terminated in a NEMA 5-
15P Plug.
Battery: The AP20 contains a battery on the front panel PC board that is not field replaceable.
AP20 Installation & Operating Guide
AP20 Installation and Operating Guide
ITEM DESCRIPTION
Power cord, straight detachable, (17250) standard Volex 17250 10 B1 blk
Screw Kit, Rack, Truss head screw & Washer (E119-01)
Hardware Kit, AP20 connector (H402)
Legal notice, AP20 Software License
Legal notice, WEEE Compliance
Disc, Manual, AP20 Installation and Operation
Release notes, AP20 software
ITEM DESCRIPTION
Connector, 9-pin M D", solder cup
Conn,25-pin M D", solder cup
Conn,25-pin F D", solder cup
Connector back-shell,9-pin D
Connector backshell,25-pin D
Document # 9301H39200 Ver. 1.2
Page 11
QTY
1
1
1
1
1
1
1
QTY
2
4
4
2
8
