Introduction - Datasat AP20 Installation And Operating Manual

Introduction

This manual explains the AP20 Audio Processor setup and operation. It contains full instructions for
installing hardware and software, setting up audio playback, configuring the system, performing
maintenance and troubleshooting, and setting up and operating optional functions.
How to Use this Guide
The guide is divided into three parts. The first part covers operations for the projectionist or "operator".
The second part covers the installation, setup and other technical functions. The third part consists of
appendices with technical details such as connector and wiring diagrams.
NOTE: Technical adjustments should only be performed by a qualified theater
technician. The appendices provide detailed information for the theater technician.
Part 1: Operation
Operating the AP20 Audio Processor
How-To Procedures
Troubleshooting – Operations
Part 2: Installation and Setup
Hardware Installation
System Software Setup and Menus
Maintenance and Troubleshooting
Part 3: Appendices
A. Connector Pin-outs
B. Interface Wiring Diagrams
C. AP20 Wiring and Block Diagrams
D. Specifications
E. Dolby® Digital Operation
F. Optical Film Card (H338) - Option
G. 8-Channel AP20 (Includes 16-Channel upgrade instructions)
AP20 Installation & Operating Guide
AP20 Installation and Operating Guide
Document # 9301H39200 Ver. 1.2
Page 6
