Audio Delays
Individual Channel Delays
0 - 1000ms (ie: 0 to 1 second delay)
Global Delay
0 – 250ms
Note: Total delay per channel not to exceed 1000ms (ie: 1 second)
35mm Film Optical Soundtrack Audio Processing (with optional H338 PCB)
Built-in processing for mono, A-Type and SR noise reduction.
Matrix decoding LT/RT to left, center, right and surround
Optical bass extension with adjustable low-pass filter and gain.
2 projector inputs for change-over operation.
Automation control for change-over.
BNC connectors for external RTA and oscilloscope.
Graphical user interface for A-chain alignment including optical gain, slit-loss EQ, and azimuth.
Automation Inputs/Outputs
Connector
DB25(GPIO)
Management
Remote Control
2 RS232 DB9s
10/100 Ethernet
Updated, controlled, and monitored via TMS using Ethernet
Remote control (optional) that controls volume, channel mutes, formats and automation (Release
TBD).
Setup/Operation Profiles
Named profiles identifying inputs, output, filter and channel gain settings
Touchscreen or automation format switching
Export/Load of user profile to additional cinema processors with identical room setups (via USB)
Power Requirements
100-240 VAC, 50-60Hz, auto-switching
60w power consumption
Hardware Dimensions
3U 19" rackmount standard
Imperial - 5.25"(H) x 19.0"(W) x 15.0"(D) Shipping Weight: 30lbs
Metric - 13.33 cm(H) x 48.25 cm(W) x 38.1 cm(D) Shipping Weight: 13.6kg
E&OE
All product specifications subject to change without notice. All trademarks are properties of their
respective owners.
Appendix D: AP20 Product Specifications
AP20 Installation and Operating Guide
D-3
Version 1.2
Document #: 9301H39200 1.2
