Example 2: Redistribution Into Ospf - Cabletron Systems SmartSwitch 8-slot User's Reference Manual

Exporting a given static route to all RIP interfaces
Router R1 has several static routes of which one is the default route. We would export
this default route over all RIP interfaces.
ip-router policy redistribute from-proto static to-proto rip network default
Exporting all static routes to all RIP interfaces
Router R1 has several static routes. We would export these routes over all RIP
interfaces.
ip-router policy redistribute from-proto static to-proto rip network all
Exporting all static routes except the default route to all RIP interfaces
Router R1 has several static routes. We would export all these routes except the default
route to all RIP interfaces.
ip-router policy redistribute from-proto static to-proto rip network all
ip-router policy redistribute from-proto static to-proto rip network default
restrict

Example 2: Redistribution into OSPF

For all examples given in this section, refer to the configurations shown in Figure 3 on
page 6 - 25.
The following configuration commands for router R1:
• Determine the IP address for each interface
• Specify the static routes configured on the router
• Determine its OSPF configuration
!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
! Create the various IP interfaces.
!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
interface create ip to-r2 address-netmask 120.190.1.1/16 port et.1.2
interface create ip to-r3
interface create ip to-r41 address-netmask
interface create ip to-r42 address-netmask
interface create ip to-r6
!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
! Configure default routes to the other subnets reachable through R2.
!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
ip add route 202.1.0.0/16 gateway 120.1.1.2
ip add route 160.1.5.0/24 gateway 120.1.1.2
!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
! OSPF Box Level Configuration
!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
ospf start
SSR User Reference Manual
Chapter 6: Routing Policy Configuration Guide
address-netmask 130.1.1.1/16 port et.1.3
140.1.1.1/24 port et.1.4
140.1.2.1/24 port et.1.5
address-netmask 140.1.3.1/24 port et.1.6
6 - 13
