Show detailed information of all
response received by the router.
Show detailed information of response
packets sent by the router.
Show detailed information of request
packets sent by the router.
Show RIP timer information.

Configuration Example

! Example configuration
!
! Create interface ssr1-if1 with ip address 1.1.1.1/16 on port
et.1.1 on SSR-1
interface create ip ssr1-if1 address-netmask 1.1.1.1/16 port
et.1.1
!
! Configure rip on SSR-1
rip add interface ssr1-if1
rip set interface ssr1-if1 version 2
rip start
!
!
! Set authentication method to md5
rip set interface ssr1-if1 authentication-method md5
!
! Change default metric-in
rip set interface ssr1-if1 metric-in 2
!
! Change default metric-out
rip set interface ssr1-if1 metric-out 3
SSR User Reference Manual
rip trace response receive
rip trace response send
rip trace send request
rip show timers
SSR 1
Interface 1.1.1.1
Chapter 4: RIP Configuration Guide
SSR 2
Interface 3.2.1.1
4 - 5
