Chapter 5: OSPF Configuration Guide
Shows routes redistributed into OSPF.
Show all OSPF global parameters.
Show information about OSPF import
policies.
Show OSPF interfaces.
Shows information about all valid next
hops mostly derived from the SPF cal-
culation.
Show OSPF statistics.
Shows information about OSPF Border
Routes.
Show OSPF timers.
Show OSPF virtual-links.

OSPF Configuration Examples

For all examples in this section, refer to the configuration shown in Figure 1 on page
5 - 12.
The following configuration commands for router R1:
• Determine the IP address for each interface
• Specify the static routes configured on the router
• Determine its OSPF configuration
!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
! Create the various IP interfaces.
!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
interface create ip to-r2 address-netmask 120.190.1.1/16 port et.1.2
interface create ip to-r3
interface create ip to-r41 address-netmask
interface create ip to-r42 address-netmask
interface create ip to-r6
!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
! Configure default routes to the other subnets reachable through R2.
!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
ip add route 202.1.0.0/16 gateway 120.1.1.2
5 - 8
ospf show exported-routes
ospf show globals
ospf show import-policies
ospf show interfaces
ospf show next-hop-list
ospf show statistics
ospf show summary-asb
ospf show timers
ospf show virtual-links
address-netmask
address-netmask
130.1.1.1/16 port et.1.3
140.1.1.1/24 port et.1.4
140.1.2.1/24 port et.1.5
140.1.3.1/24 port et.1.6
