SYSTEM OPERATION - Continued:
____ ____ Has refrigerant and oil charge been noted on the charging label? Correct type oil?
____ ____ Is charging label attached as closely as possible to the compressor?
____ ____
Is there an installation check-out sheet in use?
FINAL:
Record readings after system has been running for at least 10 minutes at high idle.
System Pressure(s): Rear or Passenger Side
Suction Pressure
Discharge Pressure _____ psig
Temperatures:
Ambient Temperature _____F
Charges:
Actual values as recorded on charging sticker in engine compartment.
Rear or Passenger Side: --- Refrigerant ______Lb ______ Oz
Front or Drivers Side: ---- Refrigerant ______Lb ______ Oz
Electrical Data:
Alternator Size _____Amps
Voltage at: Compressor Clutch ______ V
Compressor Clutch ______ V
Voltage at battery with all accessories and air conditioning on _________V
Installer/Technician
______________________________________
OEM OR INSTALLATION CENTER ----------------------------------------------------------
T--311
_____ psig
Evaporator Air Temperature In
Evaporator Air Temperature Out _____ F _____ F
Alternator current with all accessories and A/C on ____Amps
Evaporator ______ V
Evaporator ______ V
11--4
Front or Drivers Side
Suction Pressure ____ psig
Discharge Pressure ____ psig
_____ F _____ F _____ F
_____ F
Oil ______Oz
Oil ______Oz
Condenser ______V
Condenser ______V
_Date
__________________________
-----------------------------------
