1: Detailed Chassis Description

Chassis Features

2
The SGI 1450 server is designed either to be mounted in a standard 19-inch rack (rack
mode) or to stand upright (pedestal mode). Table 1-1 shows the physical specifications
for the SGI 1450 server in rack mode.
For instructions on mounting the SGI 1450 server in a 19-inch rack, see the SGI 1450
Server Mounting Instructions.
Table 1-1 SGI 1450 Server Physical Specifications
Specification
Height
Width
Depth
Weight
Required front clearance
Required rear clearance
Required side clearance
Rack Mode
4u (7 inches)
17.5-inch rack
26.5 inches
57 lbs (26 kg), minimum configuration
88 lbs (40 kg), maximum configuration
3 inches (inlet air temperature <35 °C / 95 °F)
6 inches (no airflow restriction allowed)
1 inch
007-4276-001
