Floppy Connectors

007-4276-001
Table A-15 shows the cable pinout assignments for the 34-position floppy connector.
Table A-15
34-Position Floppy Connector Pin-Out
Pin
Signal
1
NC
3
NC
5
NC
7
GND
9
GND
11
GND
13
GND
15
GND
17
GND
19
GND
21
GND
23
GND
25
GND
27
GND
29
GND
31
GND
33
GND
Peripheral Adapter Boards and Connectors
Pin
Signal
2
HD In/ HD Out/ Open
4
N/C
6
N/C
8
FD_INDEX_L
10
Drive select 0
12
Drive select 1
14
N/C
16
Motor on
18
Direction select
20
STEP
22
Write data
24
Write gate
26
Track 00
28
Write protect
30
Read data
32
Side one Select
34
Disk change/ready
