Silicon Graphics 1450 Maintenance Manual page 114

A: Technical Reference
98
Table A-10 (continued)
Pin Signal Name
10 DP(4)
11 DP(5)
12 DP(6)
13 DP(7)
14 DAPLP
15 GND
16 DIFFSENSE
17 TERMPWR
18 TERMPWR
19 NC
20 GND
21 ATNP
22 GND
23 BSYP
24 ACKP
25 RSTP
26 MSGP
27 SELP
28 CDP
29 REQP
30 IOP
31 DP(8)
32 DP(9)
External Adaptec Ultra 160/m SCSI
Pin Signal Name
44 DM(4)
45 DM(5)
46 DM(6)
47 DM(7)
48 DAPLM
49 GND
50 GND
51 TERMPWR
52 TERMPWR
53 NC
54 GND
55 ATNM
56 GND
57 BSYM
58 ACKM
59 RSTM
60 MSGM
61 SELM
62 CDM
63 REQM
64 IOM
65 DM(8)
66 DM(9)
007-4276-001
