Chassis Features
The top cover is held in place by two thumbscrews, each located at the top rear corner of
the chassis. One of two thumbscrews is noted by "A" in Figure 1-3.
A
Figure 1-3 Top Cover Thumbscrew
A bezel snaps on to the front of the chassis and allows adequate airflow to cool the system
components. The door in the bezel provides user access to hard drives and the peripheral
bay. Access to the power supplies is provided by removing the front bezel completely.
