1: Chassis Description

Chassis Features

2
The SGI 1450 server is designed to be either mounted in a standard 19-inch rack (rack
mode) or standing upright (pedestal mode). Table 1-1 shows the physical specifications
for the SGI 1450 server in rack mode.
For instructions on mounting the SGI 1450 server in a 19-inch rack, see the SGI 1450
Server Mounting Instructions.
Table 1-1 SGI 1450 Server Physical Specifications
Specification
Height
Width
Depth
Weight
Required front clearance
Required rear clearance
Required side clearance
Rack Mode
4u (7 inches)
17.5 inches (44.5 cm)
26.5 inches (67.3 cm)
57 lbs. (26 kg), minimum configuration
88 lbs. (40 kg), maximum configuration
3 inches (inlet air temperature <35 °C / 95 °F)
6 inches (no airflow restriction allowed)
1 inch
007-4274-001
