Table A-24 (continued)
Pin** Signal Pin
A037 GND B037 0_CS1
A038 0_CS2 B038 VCC3
A039 0_CS3 B039 0_MCDOE*
A040 GND B040 MEMPRSNT
A041 0_MCDSEL* B041 VCC3
A042 GND B042 TMD0
A043 GND B043 VCC3
A044 CMD34 B044 VCC3
A045 CMD50 B045 CMD49
A046 GND B046 CMD54
A047 CMD52 B047 VCC3
A048 CMD51 B048 CMD33
A049 GND B049 CMD32
A050 CMD40 B050 VCC3
A051 CMD38 B051 CMD53
A052 GND B052 CMD36
A053 CMD35 B053 VCC3
A054 CMD42 B054 CMD58
A055 GND B055 CMD39
A056 GND B056 VCC3
A057 GND B057 VCC3
A058 CMD55 B058 VCC3
A059 CMD37 B059 CMD43
A060 GND B060 CMD57
Memory Module Interface
Signal Pin Signal
A120 CMD111
A121 CMD127
A122 GND
A123 1_WE*
A124 1_CAS
A125 GND
A126 1_CS2
A127 1_CS3
A128 GND
A129 CMD80
A130 MECC8
A131 GND
A132 CMD81
A133 MECC9
A134 GND
A135 CMD66
A136 CMD82
A137 GND
A138 CMD83
A139 CMD84
A140 GND
A141 CMD87
A142 CMD70
A143 GND
Baseboard Connectors
Pin Signal
B120 VCC3
B121 CKE_1
B122 1_RAS
B123 VCC3
B124 1_CS0
B125 1_CS1
B126 VCC3
B127 1_MCDOE*
B128 1_MCDSEL*
B129 VCC3
B130 MECC10
B131 CMD64
B132 VCC3
B133 MECC11
B134 CMD65
B135 VCC3
B136 CMD85
B137 CMD67
B138 VCC3
B139 CMD68
B140 CMD71
B141 VCC3
B142 CMD86
B143 CMD69
