Removing an ICMB Card

007-4276-001
A
External Cable Attached to the Card
Figure 3-10
To remove an ICMB card, follow these steps:
1.
Disconnect the internal and external cables from the card and the baseboard.
2. Remove the screw securing the card to the chassis. The screw is noted by "A" in
Figure 3-8 on page 72.
3. Remove the ICMB card from the server.
ICMB Card
73
