A.

Internal Cables and Connectors

007-4276-001
Appendix A

Technical Reference

This appendix provides a description of the rear panel I/O ports, the peripheral adapter
board and connectors, and the baseboard connectors and jumpers.
Table A-1 describes all cables and connectors of the SGI 1450 server.
Table A-1 SGI 1450 server Cables and Connectors
Type Qty From
32-bit PCI, 5 V 2 Baseboard
64-bit PCI, 5 V 4 Baseboard
64-bit PCI, 3.3 V 2 Baseboard
Keyboard 1 Baseboard
Mouse 1 Baseboard
System control 1 Baseboard
S/M feature 1 Baseboard
Narrow SCSI 1 Baseboard
Floppy 1 Baseboard
IDE 1 Baseboard
HPIB 1 Baseboard
Auxiliary 4 Baseboard
processor fans
Parallel port 1 Baseboard
To Interconnect Description
PCI adapter card 120-pin card edge connect
PCI adapter card 184-pin card edge connect
PCI adapter card 184-pin card edge connect
External interface Keyboard device
External interface Mouse device
Fan distribution board 2x15 flat ribbon cable
Intel S/M card 2x13 flat ribbon cable
5.25-inch device 2x25 flat ribbon cable
Floppy device 2x17 flat ribbon cable
CD-ROM device 2x20 flat ribbon cable
HPIB board 2x10 flat ribbon cable
N/A 1x3-pin connector, NOT USED
FOR SGI 1450 SERVER
External interface 25-pin parallel port connector
