Operation

The DTP T EU and DTP T MK units can be controlled only by SIS commands (see
Instruction Set Control
Configuration Software
operation details. Topics in this section include:

Indications

•
•
•
•
•

Switch Modes

The switching transmitter has three switch modes:
•
•
•
These modes can be selected through SIS commands (see
on page 22) or the Product Configuration Software (see the PCS Help

EDID

To manage EDID on the DTP T EU and DTP T MK units, use SIS commands (see
commands on page 23) or the Product Configuration Software (see the PCS Help file). The
DTP T EU and DTP T MK units can record and save EDID in a user memory location, select
a pre-defined EDID, or use EDID from a display connected to a receiver. EDID stored in the
user memory location can come from the display connected to a receiver or a custom EDID
imported through the Product Software.

Reset

Use the recessed Reset button on the side of the transmitter (see
item
for approximately 6 seconds. All front panel LEDs cycle. Release the button. This reset is the
equivalent of issuing the
DTP T EU 332, DTP T EU 232, DTP T MK 332, and DTP T MK 232 • Installation and Operation
on page 19) or the Product Configuration Software (see
on page 26). This section contains basic information about
Power LED — Lights when power is applied.
HDCP LED — Lights when the HDMI input signal is encrypted.
HDMI LED — Lights when an HDMI input signal is detected.
VGA LED — Lights when a VGA input signal is detected.
Auto LED — Lights when the device is in auto switch mode.
Manual — The input must be selected manually using an SIS command
Auto switch (VGA) — The switcher automatically selects the input with an active signal
present and, if both are present, prioritizes the VGA input. This is the factory default
mode.
Auto switch (HDMI) — The switcher automatically selects the input with an active
signal present and, if both are present, prioritizes the HDMI input.
on page 8) to initiate a reset to the default settings. Press and hold the reset button
G
Reset
E }
SIS command ( ZXXX
Simple
Product
PWR HDCP HDMI VGA AUTO
Switch mode SIS commands
file).
EDID
figure 3 on page 7 and
, see page 25).
SIS
17
