Troubleshooting
Malfunction
Water appears to be leaking from the
Compressor Compact:
Water does not accumulate in the drainage
bottle at regular intervals. Drainage is too
frequent, not frequent enough, or does not
occur at all:
The operating time meter does not run when
the Compressor Compact is in operation:
46
Action
• Inspect all water tubes and connectors.
Tighten loose connectors and/or replace
damaged components.
• Inspect the drainage bottle for leaks or a
loose connection. Replace the bottle if
necessary.
• Inspect filter/water separators and replace
them if necessary.
• Inspect solenoid valves and replace them if
necessary.
• Inspect all water tubes and connectors.
Clear obstructions and/or replace faulty
components.
• Inspect filter/solenoid valves and replace
them if necessary.
• Inspect water separator 2 and replace it if
necessary.
• Replace the control section PC board.
• Malfunction in the thermoelectric cooler.
Check the function of the cooler temp.
switch as previously described. Replace
the thermoelectric cooler if necessary.
• Replace the operating time meter.
Siemens-Elema AB
Compressor Compact
E382 EH81E 061 01 03 02
