Compressor Compact
4
3
6
E382 EH81E 061 01 03 02

Compressor covers

The covers and the casing are secured with
hexagonal screws. Use a 5 mm hexagonal
wrench when removing or tightening the
screws.
Front cover
• The front cover (1) is secured with two
5
Rear cover
• The rear cover (3) is secured with four
Casing
• The casing (5) is secured with four
2
1
Siemens-Elema AB
Disassembling and assembling
Before any compressor cover or the front
panel is opened or removed, make sure
that the mains power supply is
disconnected and that the compressed
air reservoir is depressurized.
screws (2).
screws (4).
screws (6).
23
