Removing A Power Supply - Enterasys Matrix N7 7C107 Hardware Installation Manual

Setting Up the Enterasys Matrix N7 Chassis
3.2.5

Removing a Power Supply

To remove a 7C203-1 power supply, refer to
1. Attach the anti-static wrist strap as described in
supply module.
Caution: Always set the
chassis.
Precaución: Antes de quitar la fuente de poder del chasis, coloque el interruptor 0/| en
la posición 0.
2. Set the power supply 0/| Power switch to 0.
3. Unplug the power cords from each dedicated 15A/120 Vac outlet.
4. Unplug the power cord from the ac power connectors of the power supply.
5. Unscrew the captive slotted-head screw to release the power supply from the chassis.
6. To remove the power supply from the chassis, grasp the handle and pull the power supply
straight out of the chassis, then place it on an antistatic surface or in an antistatic bag for future
use.
Caution: If you plan to operate the chassis with only one power supply, make sure to
install the coverplate in place of the removed power supply to reduce Electromagnetic
Interference.
Precaución: Si desea trabajar sólo con una fuente de poder, no olvide colocar la tapa
en el compartimiento de la fuente de poder que haya eliminado, para reducir la
interferencia electromagnética.
3-14 Enterasys Matrix N7 Chassis Setup
Figure 3-8 and proceed as follows:
Section 3.2.3.3
0/|
power switch to 0 before removing a power supply from the
before handling the power
