3.2.3

Rack Mounting the Enterasys Matrix N7 Chassis

The N7 chassis can be mounted in a standard 48.26-centimeter (19-inch) equipment rack. To rack

mount the chassis into a rack you need to

•

allow at least 60 centimeters (24 inches) of clearance in front of the rack for chassis installation,

•

install the shelf into the rack first, then

•

install the N7 chassis into the rack.

Note: In order to prevent a possible interference between the rack frame front and

chassis rack ears, the tapped rails may need to be adjusted such that they are recessed

approximately 2 inches behind the rack frame front. If the rack has a front door, this

distance may need to be slightly more depending on the door thickness.

Setting Up the Enterasys Matrix N7 Chassis

Enterasys Matrix N7 Chassis Setup

3-7
