Configuration Guidelines

•
Ambient temperature at the installation site must be maintained between 5° and 40°C
(41° to 104°F). Temperature changes must be maintained within 10°C (18°F) per hour.
2.2 CONFIGURATION GUIDELINES
The N7 chassis has seven slots that accept DFE modules. The slots are numbered 1 to 7 beginning
with the leftmost slot. There are two slots near the bottom of the chassis that are strictly for power
supplies. These slots are labeled PS1 and PS2.
The DFE modules for the N7 chassis are equipped with a firmware-based management tool, which
provides the capability to configure one or more DFE modules; and access chassis, power supply,
and fan tray information.
2.3

LANVIEW LEDs

The following sections describe the LANVIEW LED indications for the following:
•
6C207-3 power supply module
•
Fan tray unit
2.3.1

Power Supply LEDs

There are two LEDs on the power supply. Refer to
LEDs. Table 2-1 describes the different states of the power supply LEDs under six different
conditions. The power supplies are installed in chassis slots PS1 and PS2 in the front-bottom part
of the chassis.
2-2 Installation Requirements and Guidelines
Figure 2-1 for the location of the power supply
