This chapter contains instructions on setting up the Enterasys Matrix N7 chassis.
Equipment needed:
•
Phillips screwdriver
•
Flat blade screwdriver
Electrical Hazard: Only qualified personnel should install or service this unit.
Riesgo Eléctrico: Nada mas personal capacitado debe de instalar o darle servicio a
esta unida.
Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch
ausgebildetes und qualifiziertes Personal vorgenommen werden.
A Phillips screwdriver is needed to install the unit in a 48.26-centimeter (19-inch) equipment rack
and to install the cable management bar. A large flat blade screwdriver is needed to secure the
power supplies and to remove and reinstall the fan tray. Refer to
must be followed to install the N7 chassis.
3.1

UNPACKING THE ENTERASYS MATRIX N7 CHASSIS

Note: Unpack the N7 chassis components only as needed. Leave the components in
their respective shipping cartons until you are ready to install that component. Save all
shipping materials in the event that the chassis has to be repacked.
The N7 chassis is packed and shipped on a skid. Before unpacking the chassis, examine the
outside packaging for obvious damage. To unpack the N7 chassis, refer to
includes numbers that correspond to the steps below, and proceed as follows:
1. Cut the two shipping straps fastening the corrugated box to the skid.
2. Lift and remove the box off the skid.
3. Remove and save four screws fastening the rear shipping bracket/shelf to the rear of the chassis.

Enterasys Matrix N7 Chassis Setup

Chapter 2 for the guidelines that
Figure
Enterasys Matrix N7 Chassis Setup
3
3-1, which
3-1
