  • Page 1 Enterasys Matrix ® 7C103 Chassis Hardware Installation Guide P/N 9033824-06...
  • Page 3 Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Notice Enterasys Networks reserves the right to make changes in specifications and other information contained in this  document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to  determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR  CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING  OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN  IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE  POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2008 Enterasys Networks, Inc. All rights reserved. Part Number: 9033824‐06 July 2008 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS MATRIX, ENTERASYS NETSIGHT, LANVIEW, WEBVIEW,  and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the  United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective  companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals...
  • Page 4 Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which  case the user may be required to take adequate measures.  Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia  de radio en cuyo caso puede ser requerido tomar medidas adecuadas. Klasse A ITE Anmerkung WARNHINWEIS: Dieses Produkt zählt zur Klasse A ( Industriebereich ). In Wohnbereichen kann es hierdurch zu  Funkstörungen kommen, daher sollten angemessene Vorkehrungen zum Schutz getroffen werden.  Product Safety This product complies with the following: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950,  EN 60825, 21 CFR 1040.10. Seguridad del Producto El producto de Enterasys cumple con lo siguiente: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950,  EN 60825, 21 CFR 1040.10. Produktsicherheit Dieses Produkt entspricht den folgenden Richtlinien: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC  60950, EN 60825, 21 CFR 1040.10. ...
  • Page 5 Electromagnetic Compatibility (EMC) This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2,  EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3.  Compatibilidad Electromágnetica (EMC) Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 2004/108/EC, EN 55022,  EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022,  EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3.  Hazardous Substances This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous Substances  (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment  (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this  product was placed on the European market after August 13, 2005, the date of enforcement for Directive  2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste.  ...
  • Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 7 VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information  Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise.  When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user  may be required to take adequate measures. Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop  eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user ...
  • Page 8 Declaration of Conformity Application of Council Directive(s): 2004/108/EC 2006/95/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 European Representative Address: Enterasys Networks, Ltd. Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 2006/95/EC EN 60950 EN 60825 Equipment Type/Environment: Networking Equipment, for use in a Commercial  or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives.
  • Page 9 ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf  of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect  to the Enterasys software program/firmware (including any accompanying documentation, hardware or media)  (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions  appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership,  corporation, limited liability company, other form of enterprise that directly or indirectly through one or more  intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement  constitutes the entire understanding between the parties, with respect to the subject matter of this Agreement. The  Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO  ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF  YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND  THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES,  AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF  LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO  ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU  AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN  (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL  DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program ...
  • Page 10 EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies  of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain  technical products to certain countries, unless a license to export the product is obtained from the U.S. Government or  an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export  Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the  Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export  Administration Regulations, in addition to the restriction on transfer set forth in Section 1 or 2 of this Agreement, You  agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a  country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Cambodia, Cuba, Georgia, Iraq,  Kazakhstan, Laos, Libya, Macau, Moldova, Mongolia, North Korea, the People’s Republic of China, Russia, Tajikistan,  Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States  Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the  technology, if such foreign produced direct product is subject to national security controls as identified on the U.S.  Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a  plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such  foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control  List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at  private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section  52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights Clause and its successors, and (iii) in  all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the  Program is considered commercial computer software in accordance with DFARS section 227.7202‐3 and its successors,  and use, duplication, or disclosure by the U.S. Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO YOU IN  WRITING BY ENTERASYS, ENTERASYS DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED,  INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY  QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON‐INFRINGEMENT WITH RESPECT TO THE  PROGRAM.  IF IMPLIED WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY IMPLIED   WARRANTIES ARE LIMITED IN DURATION TO THIRTY (30) DAYS AFTER DELIVERY OF THE PROGRAM TO  YOU. LIMITATION OF LIABILITY. IN NO EVENT SHALL ENTERASYS OR ITS SUPPLIERS BE LIABLE FOR ANY  DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS,  PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL, INCIDENTAL,  CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS) ARISING OUT OF THE USE OR INABILITY TO ...
  • Page 11 OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the  Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to  implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and  interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to  You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may  cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys  may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and  all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations  under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially  all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding  upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as  permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this  Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in  writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to  enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement  on any other occasion. 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or unenforceable, the  validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired  thereby, and that provision shall be reformed, construed and enforced to the maximum extent permissible. Any such  invalidity, illegality, or unenforceability in any jurisdiction shall not invalidate or render illegal or unenforceable such  provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms  and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and  shall return to Enterasys the Program and all copies of the Program.

  • Page 13: Table Of Contents

    Contents ABOUT THIS GUIDE Who Should Use This Guide..................xiii Structure of This Guide ....................xiii Using the Enterasys Matrix Series Manual Set.............xiv Document Conventions....................xv INTRODUCTION Overview ......................1-1 Features ......................1-2 Getting Help ....................1-5 INSTALLATION REQUIREMENTS AND GUIDELINES Installation Site Guidelines................
  • Page 14 Figures The Matrix N3 7C103 Chassis with Redundant Power Supplies ........1-2 7C203-1 Power Supply LEDs..................2-3 Fan Status LED on Chassis Front Panel................. 2-4 Chassis Bottom, Rubber Feet Placement ............... 3-3 Rack Mounting the Chassis..................... 3-5 ESD Grounding Receptacle .................... 3-5 Installing the Power Supply Module(s) ................

  • Page 15: About This Guide

    This guide is organized as follows: This preface provides preliminary information to help you use this guide and a brief summary of each chapter. It also discusses the Enterasys Matrix Series manual set and defines conventions used throughout this document.

  • Page 16: Using The Enterasys Matrix Series Manual Set

    Note: You can view and download all product documentation from the Enterasys web site: http://www.enterasys.com/support/manuals Nota: Puedes ver y bajar toda la documentacion de productos del sitio Web de Enterasys Networks en la siguiente liga: http://www.enterasys.com/support/manuals Anmerkung: Jegliche Produktdokumentationen finden sie zur Ansicht oder zum „Download“...

  • Page 17: Document Conventions

    Document Conventions DOCUMENT CONVENTIONS This guide uses the following conventions: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. Precaución: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen.
  • Page 18 Document Conventions About This Guide...

  • Page 19: Introduction

    Introduction This chapter provides an overview of the Matrix N3 7C103 Chassis and its features. Also covered in this chapter are the instructions on how to obtain additional help from Enterasys Networks™ if needed. OVERVIEW The N3 chassis provides three slots that can contain a variety of modules. The chassis backplane supports a new generation of advanced switching modules (7Hxxxx and 7Gxxxx series).

  • Page 20: Features

    Features Figure 1-1 The Matrix N3 7C103 Chassis with Redundant Power Supplies  STATUS Á 7C203-1 REDUNDANCY 100-125V~12.0A 200-240V~6.0A À 50/60 Hz 7C203-1 REDUNDANCY 100-125V~12.0A 200-240V~6.0A 50/60 Hz 1 Two slots for 7C203-1 2 Three slots for 7Hxxxx and 3 Fan Tray located at the rear...
  • Page 21 Features Redundant Power Supplies The N3 chassis supports up to two 7C203-1 power supplies in the lower two slots of the chassis labeled PS1 and PS2. One power supply provides sufficient power for a chassis that is fully loaded with modules. However, a second power supply may be installed to provide redundancy and load sharing.
  • Page 22 Features Power Supply Replacement To reduce network downtime, a power supply may be removed after it has been powered down. When two power supplies are installed, this allows you to remove one power supply without powering down the chassis and interrupting network traffic. Chassis Cooling System The N3 chassis features a removable 7C403 fan tray, which is accessible from the rear of the chassis.

  • Page 23: Getting Help

    Getting Help GETTING HELP For additional support related to the N3 chassis or this document, contact Enterasys Networks using one of the following methods: World Wide Web www.enterasys.com/support/ Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/...
  • Page 24 Getting Help Introduction...

  • Page 25: Installation Requirements And Guidelines

    Installation Requirements and Guidelines This chapter describes the following: • Site guidelines that must be met before installing the N3 chassis into a rack or cabinet • N3 chassis configuration guidelines • Operating specifications for the N3 chassis enclosure and power supply modules Electrical Hazard: Only qualified personnel should install or service this unit.

  • Page 26: Configuration Guidelines

    Configuration Guidelines • Each 7C203-1 ac power supply requires a three-pronged power receptacle capable of delivering the current and voltage specified in Section A.2. An ac outlet on a separately fused circuit is required for each 7C203-1 to provide power redundancy, and must be located within 182 centimeters (6 feet) from the site.

  • Page 27: Lanview Leds

    LANVIEW LEDs LANVIEW LEDs ® The following sections describe the LANVIEW LED indications for the following: • 7C203-1 power supply modules • 7C403 fan assembly 2.3.1 Power Supply LEDs There are two status LEDs on the power supply. Refer to Figure 2-1 for the location of the power supply LEDs.

  • Page 28: Fan Status Led

    LANVIEW LEDs Table 2-1 Power Supply (PS) LED Status Definitions PS1 LEDs PS2 LEDs Load REDUNDANCY REDUNDANCY Green Amber Amber Amber Green Amber Out of chassis Green Out of chassis Green <50% Green Green Green Green >50% Green Amber Green Amber 2.3.2 Fan Status LED...

  • Page 29: Chassis Setup

    Chassis Setup This chapter contains instructions on setting up the N3 chassis. Equipment needed: • Phillips screwdriver • Flat blade screwdriver Electrical Hazard: Only qualified personnel should install or service this unit. Riesgo Eléctrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida. Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden.

  • Page 30: Setting Up The Chassis

    Setting Up the Chassis 2. Remove the chassis from the protective plastic bag. 3. Examine the chassis carefully and check for damage. If any damage is noted, DO NOT install the chassis. Contact Enterasys Networks immediately (refer to Section 1.3).

  • Page 31: Chassis Bottom, Rubber Feet Placement

    Setting Up the Chassis To install the rubber feet, refer to Figure 3-1 and proceed as follows: 1. Place the chassis on its back on a sturdy flat surface to access the bottom of the chassis. 2. Remove the four rubber foot/screw assemblies from their plastic bag in the shipping box. 3.

  • Page 32: Rack Mounting The Chassis

    Setting Up the Chassis 3.2.3 Rack Mounting the Chassis When installing the N3 chassis into a standard 48.26-centimeter (19-inch) equipment rack, • allow at least 61 centimeters (24 inches) of clearance in front and behind the rack for chassis installation and maintenance, and •...

  • Page 33: Attaching The Electrostatic Discharge Wrist Strap

    Setting Up the Chassis Figure 3-2 Rack Mounting the Chassis Á STATUS À À Â Â 7C203-1 REDUNDANCY 100-125V~12.0A 200-240V~6.0A 50/60 Hz 7C203-1 REDUNDANCY 100-125V~12.0A 200-240V~6.0A 50/60 Hz 1 Chassis side rails 2 Equipment rack or cabinet 3 Rack mounting screws (7) 3.2.4 Attaching the Electrostatic Discharge Wrist Strap The Electrostatic Discharge (ESD) wrist strap must be attached before handling the power...

  • Page 34: Installing A Power Supply

    3. Examine the power supply carefully, checking for damage. If any damage is noted, DO NOT install the power supply. Contact Enterasys Networks immediately. 4. Slide the power supply into the slot labeled PS1 as follows: a.

  • Page 35: Installing The Power Supply Module(S)

    Setting Up the Chassis d. Secure the power supply to the chassis by using a screwdriver to tighten the two slotted screws on the front panel of the power supply. For proper chassis grounding, the screws must be properly tightened. 5.

  • Page 36: Removing A Power Supply

    Setting Up the Chassis After completing the power supply and module installations, the chassis is ready to be powered up. Proceed to Section 3.2.6 for instructions to power up the chassis. 3.2.6 Removing a Power Supply To remove a 7C203-1 power supply, refer to Section 3.2.5 and proceed as follows: 1.

  • Page 37: Removing A Power Supply From A Powered Up Chassis

    Setting Up the Chassis Figure 3-5 Removing a Power Supply from a Powered Up Chassis Æ STATUS Ç 7C203-1 7C203-1 REDUNDANCY REDUNDANCY 100-125V~12.0A 200-240V~6.0A 50/60 Hz 100-125V~12.0A 200-240V~6.0A 50/60 Hz Å Ä À Ã Å 1 Power switch 4 AC power connector 7 N3 chassis 2 AC power cord 5 Power supply...

  • Page 38: Powering Up The Chassis

    Powering Up the Chassis POWERING UP THE CHASSIS To power up the chassis, refer to Figure 3-6 and proceed as follows: NOTE: If two power supplies are going to be installed, repeat the following procedure for each power supply. For proper redundancy using two 7C203-1 power supplies, the power cord from each power supply must be connected to a dedicated 15-Ampere ac power circuit.

  • Page 39: Removing And Reinstalling The Fan Tray

    LEDs, refer back to Section 2.3. If you experience any problems with this installation, contact Enterasys Networks for assistance. REMOVING AND REINSTALLING THE FAN TRAY The N3 chassis is factory equipped with a removable fan tray 7C403. This allows for easy periodic cleaning and/or replacement if a problem occurs with fan operation.

  • Page 40: Removing The Fan Tray

    Removing and Reinstalling the Fan Tray Figure 3-7 Removing the Fan Tray Ä Ã Â Ã Ã Â Á À Ã 1 Fan tray 4 Captive screws 2 7C103 chassis 5 Self-aligning ac power connector 3 Fan Tray handles 3-12 Chassis Setup...

  • Page 41: Reinstalling The Fan Tray

    Removing and Reinstalling the Fan Tray 3.4.2 Reinstalling the Fan Tray To reinstall the fan tray, refer back to Figure 3-7 and proceed as follows: 1. Locate the ESD wrist strap shipped with the N3 chassis. Attach the ESD wrist strap to your wrist and plug the cable from the ESD wrist strap into the ESD grounding receptacle at the front upper-right corner of the chassis.
  • Page 42 Removing and Reinstalling the Fan Tray 3-14 Chassis Setup...

  • Page 43: Specifications And Regulatory Compliance

    7C403 fan tray. Enterasys Networks reserves the right to change the specifications at any time without notice. PHYSICAL SPECIFICATIONS The physical specifications for the Matrix N3 7C103 chassis, the 7C203-1 power supply module, and the 7C403 fan tray are as follows: 7C103 Chassis...
  • Page 44 Power Supply Requirements 7C403 Fan Tray Item Specification Physical Dimensions: 27.62 H x 33.0 W x 4.13 D (cm) 10.875 H x 13.0 W x 1.625 D (in.) Weight: 2.27 kg (5.0 lb) Mean Time Between Failures (MTBF): 1,712,590 hours POWER SUPPLY REQUIREMENTS The requirements for the 7C203-1 ac power supply module are as follows: Item...
  • Page 45 33.60 1/4 – 20 63.65 67.0 70.35 ENVIRONMENTAL REQUIREMENTS The environmental requirements for the Matrix N3 7C103 chassis, 7C203-1 power supply module, and 7C403 fan tray are as follows: Item Specification Operating Temperature: 5°C to 40°C (41°F to 104°F) Storage Temperature: -30°C to 73°C (-22°F to 164°F)
  • Page 46 Regulatory Compliance Specifications and Regulatory Compliance...
