SecureStack C2
Redundant Power Supply Chassis
C2RPS-CHAS2
Installation Guide
Caution:
Do not use this product with SecureStack PoE devices. Any
SecureStack device with a "P" suffix in the model number (C2xxxx-xxP)
indicates a SecureStack PoE-compliant device and is not compatible with
this power system
Precaución: El RPS no es compatible con switches SecureStack C2 con
PoE. No intente conectar el cable de corriente del RPS a ningún switch
SecureStack C2 que tenga el sufijo "P" en el nombre del modelo, tal como
C2xxxxx-xxP. De lo contrario, el dispositivo puede dañarse.
9034091-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enterasys SecureStack C2RPS-CHAS2
Summary of Contents for Enterasys SecureStack C2RPS-CHAS2
-
Page 1: Installation Guide
SecureStack C2 Redundant Power Supply Chassis C2RPS-CHAS2 Installation Guide Caution: Do not use this product with SecureStack PoE devices. Any SecureStack device with a “P” suffix in the model number (C2xxxx-xxP) indicates a SecureStack PoE-compliant device and is not compatible with this power system Precaución: El RPS no es compatible con switches SecureStack C2 con... - Page 3 Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2005 Enterasys Networks, Inc. All rights reserved. Part Number: 9034091‐01 April 2005 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS MATRIX, LANVIEW, MATRIX, NETSIGHT, WEBVIEW, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals...
-
Page 4: Product Safety
Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Notice This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia ... - Page 5 Electromagnetic Compatibility (EMC) This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. Compatibilidad Electromágnetica (EMC) Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 89/336/EEC, EN 55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 6: Declaration Of Conformity
Application of Council Directive(s): 89/336/EEC European Representative Address: Enterasys Networks, Ltd. Conformance to Directive(s)/Product Standards: EC Directive 89/336/EEC Equipment Type/Environment: Networking Equipment, for use in a Commercial Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. Declaration of Conformity 73/23/EEC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 73/23/EEC EN 60950 or Light Industrial Environment. - Page 7 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc. on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware installed on the Enterasys product (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, or other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, and supersedes all prior discussions, representations, understandings or agreements, whether oral or in writing, between the parties with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program provided in this package subject to the terms and conditions of this Agreement. RESTRICTIONS. Except as otherwise authorized in writing by Enterasys, You may not, nor may You permit any third party to: (i) Reverse engineer, decompile, disassemble or modify the Program, in whole or in part, including for reasons of error correction or interoperability, except to the extent expressly permitted by applicable law and to the extent the parties shall not be permitted by that applicable law, such rights are expressly excluded. Information necessary to achieve interoperability or correct errors is available from Enterasys upon request and upon payment of Enterasys’ applicable fee. (ii) Incorporate the Program, in whole or in part, in any other product or create derivative works based on the ...
- Page 8 APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions. You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the 1980 United Nations Convention on Contracts for the International Sale of Goods, the United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the Program is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China, Romania, Russia, Rwanda, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202‐3 and its successors, and use, duplication, or disclosure by the Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO YOU IN WRITING BY Enterasys, Enterasys DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON‐ INFRINGEMENT WITH RESPECT TO THE PROGRAM. IF IMPLIED WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THIRTY (30) DAYS AFTER DELIVERY OF THE PROGRAM TO YOU. ...
- Page 9 AUDIT RIGHTS. You hereby acknowledge that the intellectual property rights associated with the Program are of critical value to Enterasys and, accordingly, You hereby agree to maintain complete books, records and accounts showing (i) license fees due and paid, and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and its authorized representatives, upon reasonable notice, the right to audit and examine during Your normal business hours, Your books, records, accounts and hardware devices upon which the Program may be deployed to verify compliance with this Agreement, including the verification of the license fees due and paid Enterasys and the use, copying and deployment of the Program. Enterasys’ right of examination shall be exercised reasonably, in good faith and in a manner calculated to not unreasonably interfere with Your business. In the event such audit discovers non‐compliance with this Agreement, including copies of the Program made, used or deployed in breach of this Agreement, You shall promptly pay to Enterasys the appropriate license fees. Enterasys reserves the right, to be exercised in its sole discretion and without prior notice, to terminate this license, effective immediately, for failure to comply with this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock or assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to ...
- Page 10 viii...
-
Page 11: Table Of Contents
C2RPS-PSM Redundant Power Supply Output Connector ... A-2 Compliance Standards ... A-3 Figures SecureStack C2RPS-CHAS2 (front view without PSM)...1-2 SecureStack C2RPS-CHAS2 (front view with two PSMs) ...1-2 SecureStack C2RPS-CHAS2 (rear view with two PSMs) ...1-2 C2RPS-PSM (front view) ...1-3 C2RPS-PSM (rear view) ...1-3 RPS Supporting Two SecureStack Switches...1-4... - Page 12 Tables Contents of C2RPS-CHAS2 Carton...2-2 Contents of C2RPS-PSM Carton ...2-2 C2RPS-CHAS2 Specifications... A-1 C2RPS-PSM Specifications ... A-2 C2RPS-PSM Redundant Power Supply Connector Pin Functions ... A-3 Compliance Standards... A-3...
-
Page 13: About This Guide
• RPS refers to a complete redundant power system, which includes a C2RPS-CHAS2 chassis and optional power supply modules. • Chassis refers to the C2RPS-CHAS2 chassis. • PSM refers to the C2RPS-PSM power supply module. • PSM cable refers to the C2RPS-PSM Cable (12 Vdc power cable). Who Should Use This Guide This guide is intended for a network administrator responsible for installing and setting ... -
Page 14: Related Documents
The features and capabilities of the C2RPS-CHAS2 chassis and optional power supply modules. This chapter also provides the instructions for obtaining help from Enterasys Networks, if needed. Instructions to install an RPS into a standard 19-inch rack. This involves installing the C2RPS-CHAS2 chassis, one or two PSMs, PSM interconnecting cables, and AC power cords. -
Page 15: Conventions Used In This Guide
Conventions Used in This Guide Conventions Used in This Guide The following conventions are used in this guide: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. Precautión: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen. - Page 16 Conventions Used in This Guide xiv About This Guide...
-
Page 17: Chapter 1: Introduction
This chapter provides a functional overview of a Redundant Power System (RPS). For information about... RPS Overview C2RPS-CHAS2 Chassis C2RPS-PSM Power Supply Module RPS Deployment Strategies Getting Help Overview An RPS (redundant power system) consisting of a C2RPS‐CHAS2 chassis and C2RPS‐PSM power supplies is a simple and economical solution to provide backup power for one or two SecureStack C2 Ethernet switch devices (one for each switch device). When a C2RPS‐PSM is connected to a switch device, it continuously monitors the internal power supply of the switch device. If a power interruption is detected, the C2RPS‐PSM is automatically triggered to provide power for the switch device, preventing an interruption in network traffic. The end result is a more reliable network infrastructure, protecting the network from a single source of failure from a network device power supply. Depending on your system requirements, the C2RPS‐CHAS2 chassis can consist of the following components to provide redundant power for one or two switch devices: • One C2RPS‐CHAS2 chassis • One or two C2RPS‐PSMs (one per SecureStack switch device) • One or two AC power cords (one per C2RPS‐PSM) • One or two C2RPS‐PSM Cables (one per C2RPS‐PSM) Note: The chassis is shipped without a PSM. The PSMs are ordered separately. Each... -
Page 18: C2Rps-Chas2 Chassis
C2RPS-CHAS2 Chassis The chassis is a two‐slot frame without AC power connections or electronics. The chassis can be installed in a standard 19‐inch rack and populated with one or two PSMs. Each PSM operates independently. Figure PSMs. Figure 1‐2 and Figure chassis. Figure 1-1 _______________________________________________________________________________ Figure 1-2 _______________________________________________________________________________ Figure 1-3 _______________________________________________________________________________ 1-2 Introduction 1‐1 shows the front view of the chassis without 1‐3 show the front and rear views of a fully populated SecureStack C2RPS-CHAS2 (front view without PSM) SecureStack C2RPS-CHAS2 (front view with two PSMs) SecureStack C2RPS-CHAS2 (rear view with two PSMs) -
Page 19: C2Rps-Psm Power Supply Module
Front panel Status LED that indicates if the PSM is operating correctly. Figures 1‐4 and 1‐5 show the front and rear view of the C2RPS‐PSM. Figure 1-4 Â 1 Intake cooling fans 2 AC power LED Figure 1-5 1 Redundant Power Supply connector (12 Vdc inputs and PSM status outputs) C2RPS-PSM (front view) C2RPS-PSM (rear view) À C2RPS-PSM Power Supply Module À Á... -
Page 20: Rps Deployment Strategies
1 C2RPS-CHAS2 chassis (front view with two PSMs) 2 C2RPS-PSM Cables for 12 Vdc and status information from PSMs Note: The C2RPS-PSMs used in C2RPS-CHAS2 are interchangeable with those used in the C2RPS-CHAS8 chassis available from Enterasys Networks. 1-4 Introduction RPS Supporting Two SecureStack Switches Á... -
Page 21: Getting Help
• Any previous Return Material Authorization (RMA) numbers http://www.enterasys.com/support 603-332-9400 1-800-872-8440 (toll-free in U.S. and Canada) For the Enterasys Networks Support toll-free number in your country: http://www.enterasys.com/support/gtac-all.html support@enterasys.com To expedite your message, please type [C-SERIES] in the subject line. Getting Help SecureStack C2 Installation Guide 1-5... - Page 22 Getting Help 1-6 Introduction...
-
Page 23: Chapter 2: Installation
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. This chapter provides instructions to install all the components of an RPS. To correctly install an RPS, follow the order of information listed below. For information about... Required Tools Unpacking Chassis and Power Supply Module(s) Installing C2RPS-PSMs Installing C2RPS-CHAS2 into the Rack Connecting the PSM Cables and AC Power Cords Required Tools A flat‐blade screwdriver is required to install the C2RPS‐CHAS2 and C2RPS‐PSMs. -
Page 24: Installing C2Rps-Psms
C2RPS-CHAS2 This guide, SecureStack C2 Installation Guide (9034091-xx) Release Notes Table 2-2 Contents of C2RPS-PSM Carton Item C2RPS-PSM 150 Watt DC Power Supply Module USA, NEMA Power Cord C2RPS-PSM Cable Notice Card Installing C2RPS-PSMs Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic equipment. -
Page 25: Replacing An Installed C2Rps-Psm
Figure 2-1 C2RPS-PSM Installation À 1 C2RPS-CHAS2 chassis 2 C2RPS-PSM power supply module Replacing an Installed C2RPS-PSM To replace a PSM installed in an operating system, proceed as follows: Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic equipment. Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de seguridad para evitar descargas de electricidad estática. -
Page 26: Installing C2Rps-Chas2 Into The Rack
Installing C2RPS-CHAS2 into the Rack Note: If you plan to remove and not replace a C2RPS-PSM, immediately reinstall coverplates over any empty power supply slots to prevent EMI leakage from the chassis. To install a PSM, proceed as follows: Align the PSM with the slot, then slide the PSM forward until its front panel is flush against the chassis front panel. Fasten the PSM to the chassis using the captive screws. Perform steps 1 and 2 for each PSM being replaced. When completed, proceed to “Connecting the PSM Cables and AC Power Cords” on page 2‐6. Installing C2RPS-CHAS2 into the Rack To install the chassis into a 19‐inch (48.3‐cm) rack, you need four user‐supplied screws to ... -
Page 27: Rack Mounting The Chassis
Caution: To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 10.16 cm (4.0 in.) at the front and rear of the N-POE Chassis. Precaución: Para asegurar una buena ventilación y evitar que el sistema se sobrecaliente, deje un espacio mínimo de 10.16 cm (4 pulgadas.) con respecto a la parte delantera y trasera del chasis N- POE. -
Page 28: Connecting The Psm Cables And Ac Power Cords
Check the AC power cord connection at the AC power source and make sure the power source is within specification. b. Check the AC power connection to the PSM. Swap the AC power cord with a known good one. d. If the green LED continues to remain off, contact Enterasys Networks. Refer to “Getting Help” on page 1‐5 for instructions. Otherwise, proceed to step 4. If installing two PSM power supplies, repeat steps 1 through 3 for the second PSM. Figure 2-3 Figure 2-4 1 Redundant Power Supply connector 2-6 Installation 2‐4, then plug the AC power cord into the main AC power outlet. C2RPS-PSM Cable Power Connectors on C2RPS-PSM (rear view) À Power Cords 2‐3) to the Redundant Á 2 AC power connector (rear of chassis) -
Page 29: C2Rps-Psm Cable And Ac Power Cord Connections
Connecting the PSM Cables and AC Power Cords À Á Ä 4 Switch device Redundant Power Supply connector 5 AC power cord (type varies depending on country) 6 AC power outlet with ground connection (type varies depending on country) SecureStack C2 Installation Guide 2-7 Ã... - Page 30 Connecting the PSM Cables and AC Power Cords 2-8 Installation...
-
Page 31: A-1 C2Rps-Chas2 Specifications
This appendix includes specifications for the C2RPS‐CHAS2, C2RPS‐PSM, 12‐Vdc power supply output connector, and provides the Compliance Standards. For information about... C2RPS-CHAS2 Chassis Specifications C2RPS-PSM Specifications C2RPS-PSM Redundant Power Supply Output Connector Compliance Standards Enterasys Networks reserves the right to change the specifications at any time without notice. C2RPS-CHAS2 Chassis Specifications Table A‐1 provides the physical specifications for the C2RPS‐CHAS2. Table A-1 C2RPS-CHAS2 Specifications Item Power supply slots Dimensions without mounting brackets Net Weight (Unit Only) -
Page 32: C2Rps-Psm Specifications
The use of non-approved cables will void your warranty. Figure A-1 A-2 Specifications A‐2 for the input/output port specifications. C2RPS-PSM Redundant Power Supply Connector Pin Locations Specification 47–63 Hz 85–264 Vac 12 Vdc 1.0 A min., 8.5 A or 13.0 A max. -
Page 33: A-4 Compliance Standards
Table A-3 C2RPS-PSM Redundant Power Supply Connector Pin Functions Pin Number Compliance Standards The C2RPS‐PSM meets the safety and electromagnetic compatibility (EMC) requirements listed in Table Table A-4 Compliance Standards Item Safety Electromagnetic Compatibility (EMC) (Applies to RPS system with two modules installed and working with two network devices.) Function Ground... - Page 34 Compliance Standards A-4 Specifications...
