3. Ensure that the Power LED on each power supply is green.
4. Ensure that all fans in the fan tray unit are operating properly when power is received from the
power supply modules (fan tray LED will be green). For more information on the power supply
LEDs (Power and Fan), refer to
If you experience any problems with this installation, contact Enterasys Networks for assistance.
3.4

REMOVING AND REINSTALLING THE FAN TRAY

The N7 chassis is equipped at the factory with a removable fan tray that allows for easy periodic
cleaning and/or replacement if a problem occurs with fan operation. A flat blade screwdriver is
needed to remove and reinstall the fan tray. To remove and reinstall the fan tray, refer to
Section 3.4.1
and
Section
Caution: The fan assembly is hot-swappable. However, do not run the chassis for any
extended periods of time without an operating fan assembly, as the chassis will quickly
overheat and cause damage.
Precaución: El sistema de ventilación se puede reemplazar cuando la unidad está
encendida. Sin embargo, no utilice el chasis durante largos períodos sin contar con un
sistema de ventilación porque podría sobrecalentarse y dañarse.
3.4.1

Removing the Fan Tray

To remove the fan tray, refer to
1. Locate the ESD wrist strap shipped with the N7 chassis. Attach the ESD wrist strap to your wrist
and plug the cable from the ESD wrist strap into the ESD grounding receptacle at the upper right
corner of the chassis.
2. Use the flat blade screwdriver to loosen the slotted screws located on either side of the fan tray.
3. Slowly slide the fan tray out of its slot in the bottom of the chassis.
Section
2.3.
3.4.2.
Figure 3-10
and proceed as follows:
Removing and Reinstalling the Fan Tray
Enterasys Matrix N7 Chassis Setup
3-17
