3.2.3.2
Installing the Enterasys Matrix N7 Chassis
Caution: Read
installation guidelines are met.
Precaución: Antes de llevar a cabo el siguiente procedimiento, lea
asegúrese de cumplir con todos los requisitos de instalación.
To install the N7 chassis, proceed as follows:
Warning: To help prevent personal injury, at least two people are required to lift the
chassis into the rack.
Advertencia: Para ayudar a prevenir alguna lesión personal , al menos dos personas son
requeridas para levantar el chasis y meterlo al rack.
Warnhinweis: Zum Schutz vor körperlichen Schäden, sollten sie mit min. zwei
Personen das Chassis in das Rack heben.
1. Lift the chassis onto the shelf and slide it all the way into the rack. Refer back to
2. Use 10 screws (5 per side) provided with the equipment rack to secure the chassis to the rack,
starting with the bottom holes and working toward the top of the chassis, as shown in
Note: Refer to
installing the N7 chassis using standard threaded fastener machine screws and bolts.
Chapter 2
before completing the following procedure to ensure that all
Table A-1
on
page A-2
Setting Up the Enterasys Matrix N7 Chassis
for recommended torque values to use when
Enterasys Matrix N7 Chassis Setup
Chapter 2
para y
Figure
3-4, B.
Figure
3-5.
3-9
