Introduction; Overview - Enterasys Matrix N7 7C107 Hardware Installation Manual

This chapter provides an overview of the Enterasys Matrix N7 chassis and its features. Also
covered in this chapter are the instructions on how to obtain additional help from Enterasys
Networks if needed.
1.1

OVERVIEW

The N7 chassis design provides seven slots for a new advanced generation of modules, the Matrix
DFE series modules. All DFE modules installed in the N7 chassis operate as a system with a single
IP address.
The N7 chassis
•
uses a distributed switching architecture,
•
allows hot swapping of the DFE modules,
•
supports redundant power supplies, and
•
can be installed as a freestanding unit or installed into a standard 48.26-centimeter (19-inch)
rack.
All chassis components (power supplies, fan tray, and modules) are installed from the front of the
chassis for ease of maintenance. All LED indicators are observable from the front of the chassis to
aid in monitoring network operational status and performing maintenance.
the Enterasys Matrix N7 chassis equipped with two 1600-Watt, 6C207-3 redundant power
supplies.

Introduction

Figure 1-1 illustrates
