- Page 1 Enterasys K-Series K10 Chassis Hardware Installation Guide P/N 9034568-04...
- Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
- Page 4 Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 5 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ or contact Enterasys Customer Support at 353 61 705586 (Ireland). Battery Notice This product contains a battery used to maintain product information.
- Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
- Page 7 Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments.
- Page 8 EC Directive 2006/95/EC EN 60950-1:2006 A11:2009 A1:2010 EN 60825-1:2007 EN 60825-2:2004 A1:2007 Equipment Type/Environment: Information Technology Equipment, for use in a Commercial or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives.
- Page 9 CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package...
- Page 10 Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion.
- Page 11 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return...
-
Page 13: Table Of Contents
Contents About This Guide Who Should Use This Guide ..........................xv How to Use This Guide .............................xv Related Documents ............................xvi Typographical Conventions ..........................xvi Getting Help ..............................xvii Registering Your Product ..........................xvii Chapter 1: Introduction Overview ................................. 1-1 Features ................................. 1-3 K-Series Fabric Cards .......................... - Page 14 Required Tools ............................3-21 Preparation ............................. 3-21 Installing the Fabric Card ........................3-21 Removing the Fabric Card ........................3-24 Installing and Removing a Line Card ......................3-25 Required Tools ............................3-25 Preparation ............................. 3-25 Installing a Line Card ..........................3-26 Removing a Line Card ...........................
- Page 15 Management of PoE Power to PDs ........................B-2 Appendix C: Mode Switch Bank Setting and Memory Replacement Required Tools ...............................C-1 Setting the Mode Switches ..........................C-1 Memory Location and Replacement Procedure .....................C-3 Location of DIMM .............................C-3 Replacement Procedure ..........................C-3 Appendix D: Purchasing Mini-RJ21 Cables Mini-RJ21 to Mini-RJ21 ..........................D-2 Mini-RJ21 Angled to Mini-RJ21 Angled ......................D-2 Mini-RJ21 to Mini-RJ21 Angled ........................D-3...
- Page 16 K-AC-PS-1400W Power Supply Specifications ..................A-2 K10-FAN Fan Tray Specifications ......................A-2 Recommended Torque Values by Screw Size ...................A-3 COM Port Pin Assignments ........................A-3 Compliance Standards ........................A-4 Powered Device Classifications ......................B-1 Airborne Dust Specification for Enterasys Equipment — Airborne Dust Maximum Values....E-6...
-
Page 17: About This Guide
A brief summary of each chapter • Definitions of the conventions used in this document • Instructions regarding how to obtain technical support from Enterasys Networks. To locate information about various subjects in this guide, refer to the following table. For... Refer to... -
Page 18: Related Documents
Related Documents Related Documents Additional K-Series documentation can be obtained at the following site: https://extranet.enterasys.com/downloads/ Typographical Conventions The following typographical conventions and icons are used in this document. blue type Indicates a hypertext link. When reading this document online, click the text in blue to go to the referenced figure, table, or section. -
Page 19: Getting Help
A description of any action(s) already taken to resolve the problem (for example, changing mode switches or rebooting the unit) • The serial and revision numbers of all involved Enterasys Networks products in the network • A description of your network environment (such as layout, cable type, other relevant environmental information) •... - Page 20 Registering Your Product xviii About This Guide...
-
Page 21: Chapter 1: Introduction
All LED indicators are observable from the front of the chassis to aid in monitoring network operational status and performing maintenance. The K10 chassis can be installed by itself or with a K-POE-4BAY PoE shelf to provide additional PoE power. Enterasys K-Series K10 Chassis Hardware Installation Guide 1-1... -
Page 22: K10 Chassis Front View
Overview Figure 1-1 shows the K10 chassis with slots for one fabric card, ten line cards, and four 1400 watt, dual output, redundant power supplies. Figure 1-2 shows rear of the K10 chassis. Figure 1-1 K10 Chassis Front View Line card slots Fan slot Fabric card slot Power supply slots... -
Page 23: Features
Power supply status (normal/fault/not installed) • Power supply redundancy indication (redundant/not available) Refer to the Enterasys K-Series Configuration Guide for instructions on how to access power supply status information using Local Management. Enterasys K-Series K10 Chassis Hardware Installation Guide 1-3... -
Page 24: Auto-Ranging Input Voltage And Frequency
Features Auto-Ranging Input Voltage and Frequency The K-Series AC power supplies automatically adjust to the input voltage and frequency, which allows for an input voltage of 100 to 240 Vac, and a frequency between 50 and 60 Hz. See the operating specifications in Appendix Specifications and Regulatory... -
Page 25: Chapter 2: Installation Requirements And Guidelines
One AC outlet on an independently fused circuit is required for each power supply, and must be located within three meters (9.84 feet) of the site. The power cord used and type of outlet is dependent on the country. Enterasys K-Series K10 Chassis Hardware Installation Guide 2-1... -
Page 26: Restrictions
Warning: Install the Enterasys K-POE-4BAY PoE shelf in a Restricted Access Location only. Access to the equipment by users must be restricted through the use of a tool or lock and key or other means of security and is controlled by the authority responsible for the location. - Page 27 Completing the Installation 3-35 Important Notice Read the Release Notes specific to the firmware image running in the chassis to check for any exceptions to the supported features and operation documented in this guide. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-1...
-
Page 28: Required Tools
Lift and remove the chassis from the box. Save all shipping materials for future reshipping, if necessary. Inspect the chassis for any signs of physical damage. If there are any signs of damage, DO NOT install the chassis; instead, contact Enterasys Networks. Refer to “Getting Help”... -
Page 29: Installing The K Chassis
PoE power, refer to the K-POE-4BAY PoE Shelf Hardware Installation Guide for information on installing the PoE shelf, installing the power supplies, and powering up the power supplies in the PoE shelf. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-3... -
Page 30: Installing Rubber Feet
Installing the K Chassis Installing Rubber Feet To install the rubber feet in the K10 chassis for freestanding installation: Place the chassis on its side on a sturdy flat surface to access the bottom of the chassis. Remove the four rubber feet/screw assemblies from their plastic bag in the shipping box. Locate the four tapped holes in the four corners on the bottom of the chassis. -
Page 31: Rack Mounting The K Chassis
Esto ayuda a prevenir que el rack este demasiado pesado en la parte superior. Warnhinweis: Falls das Rack nicht mit Schrauben am Boden gesichert wird, sollte das Chassis in der unteren Hälfte des Racks installiert werden, um ein kippen des Racks zu vermeiden. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-5... -
Page 32: Front Mounting A K Chassis
Installing the K Chassis Caution: Read Chapter 2 before completing the following procedure to ensure that all installation guidelines are met. Precaución: Antes de llevar a cabo el siguiente procedimiento, lea Chapter 2 para y asegúrese de cumplir con todos los requisitos de instalación. Front Mounting a K Chassis To install the K10 chassis in a rack using the K10 chassis front mounting brackets: Warning: To help prevent personal injury, at least two people are required to lift the chassis into... -
Page 33: Mid-Mounting A K Chassis
Table A-5 on page A-3 for recommended torque values to use when installing the K10 chassis using standard threaded fastener machine screws and bolts. Figure 3-4 Mid-Mounting the K10 Chassis in a Rack Enterasys K-Series K10 Chassis Hardware Installation Guide 3-7... -
Page 34: Installing The Cable Management Clips
Installing the K Chassis Installing the Cable Management Clips Note: Installing the cable management clips is optional. If your installation location does not have the space needed for installing the cable management clips (for example, in an enclosed rack), do not install the cable management clips. -
Page 35: Closing A Cable Management Clip
Close each cable management clip by snapping its swing arm into the cable management clip below. See Figure 3-7. Figure 3-7 Closing a Cable Management Clip Figure 3-8 shows the completed installation. Figure 3-8 K10 Chassis with Cable Management Clips Enterasys K-Series K10 Chassis Hardware Installation Guide 3-9... -
Page 36: Chassis Bonding And Grounding
Installing the K Chassis Once you have installed and cabled a K-Series fabric card or line card, open the appropriate cable management clip by pushing up on the latch of its swing arm where it attaches to the cable management clip below. See Figure 3-9. -
Page 37: Telcordia Gr-1089 Grounding Hole Pattern
In Norway, Sweden, and Finland, the same procedure can be used for a permanent protective earth ground connection as required by their national deviation to IEC 60950, Section 5.1.7. • In Denmark, the chassis must be installed utilizing a Type B grounded plug. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-11... -
Page 38: Attaching The Electrostatic Discharge Wrist Strap
Attaching the Electrostatic Discharge Wrist Strap Attaching the Electrostatic Discharge Wrist Strap The Electrostatic Discharge (ESD) wrist strap must be attached before handling the power supplies, fan tray, fabric card, and line cards used in the K10 chassis. In addition, observe all precautions when handling these modules to prevent damage from electrostatic discharge. -
Page 39: Power Supply Planning
Remove the power supply from its protective plastic bag. Examine the power supply carefully, checking for damage. If any damage is noted, DO NOT install the power supply. Contact Enterasys Networks immediately. Refer to “Getting Help” on page xvii for details. -
Page 40: Installing A Power Supply
Installing and Removing a Power Supply Installing a Power Supply You must install at least one K-Series AC power supply in the K10 chassis. Depending on your module configuration, one power supply may provide sufficient power to the chassis, but multiple power supplies can be installed to provide a redundant, load sharing power source. -
Page 41: Installing A K-Series Ac Power Supply
Precaución: Colocar de manera forzada una fuente de poder o no colocarla bien alineada podría dañarla y/o maltratar el panel posterior del chasis. Secure the power supply to the chassis by screwing the captive screws into the chassis. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-15... -
Page 42: Removing A Power Supply
Installing and Removing a Power Supply If you are installing more than one power supply, remove the coverplates from the applicable number of power supply slots, as shown in Figure 3-14. Keep the coverplates in the event you need to remove the power supplies. Figure 3-14 Removing a Coverplate from a Power Supply Slot Power supply slot... -
Page 43: Installing The Power Cord Clip Assembly
Slide the clamp piece onto the strap piece with the tab on the clamp piece facing out. See Figure 3-15. Insert the power cord in the open clamp. Close the clamp piece. To open the clamp piece, push down the tab. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-17... -
Page 44: Installing And Removing A Fan Tray
Installing and Removing a Fan Tray Installing and Removing a Fan Tray The K10 chassis is equipped at the factory with one removable fan tray that allows for easy periodic cleaning and/or replacement if a problem occurs with fan operation. Caution: The fan assembly is hot-swappable. -
Page 45: Installing The Fan Tray
Installing and Removing a Fan Tray Figure 3-16 Installing the Fan Tray Captive screw Fan tray handle Chassis screw hole Tighten the captive screw to secure the fan tray to the K10 chassis. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-19... -
Page 46: Removing A Fan Tray
Installing and Removing a Fan Tray Removing a Fan Tray To remove a fan tray: Attach the anti-static wrist strap as described in “Attaching the Electrostatic Discharge Wrist Strap” on page 3-12 before handling the fan tray. Loosen the captive screw located at the top of the fan tray. Slowly slide the fan tray out of its slot in the chassis. -
Page 47: Installing And Removing The Fabric Card
Observe all precautions to prevent damage from Electrostatic Discharge (ESD). Save the bag in the event the fabric card must be reshipped. Examine the fabric card for damage. If any damage exists, DO NOT install the fabric card. Immediately contact Enterasys Networks. Refer to “Getting Help”on page xvii. -
Page 48: Inserting The Fabric Card Into The Chassis
Installing and Removing the Fabric Card To install a K-Series fabric card: Open the ejector handles of the fabric card. The open position is approximately a 45° angle away from the fabric card faceplate. The ejector handles must be open when inserting the fabric card to allow the fabric card to be installed properly. -
Page 49: Engaging The Fabric Card Ejector Handles
Installing and Removing the Fabric Card Figure 3-19 Engaging the Fabric Card Ejector Handles Captive screw Tighten the captive screws on the fabric card’s ejector handles. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-23... -
Page 50: Removing The Fabric Card
Installing and Removing the Fabric Card Removing the Fabric Card To remove the fabric card from the chassis: Loosen the captive screws on the fabric card’s ejector handles. Press the OFFLINE/RESET button. (Refer to Figure 4-6 on page 4-7 for the location of the OFFLINE/RESET button and CPU LED.) The CPU LED changes from solid green to blinking green and amber to solid amber. -
Page 51: Installing And Removing A Line Card
Observe all precautions to prevent damage from Electrostatic Discharge (ESD). Save the bag in the event the line card must be reshipped. Examine the line card for damage. If any damage exists, DO NOT install the line card. Immediately contact Enterasys Networks. Refer to “Getting Help”on page xvii. -
Page 52: Installing A Line Card
Installing and Removing a Line Card Installing a Line Card Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Caution: Failure to observe static safety precautions could cause damage to the K-Series module. -
Page 53: Inserting A Line Card Into The Chassis
Figure 3-24 Engaging the Line Card Ejector Handles Captive screw Tighten the captive screw on the line card’s ejector handle. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-27... -
Page 54: Removing A Line Card
Installing and Removing a Line Card Removing a Line Card Press the OFFLINE button and wait for the STATUS LED to change from green to amber to off. Figure 3-25. When the STATUS LED goes off, you can safely remove the K-Series line card from the chassis. -
Page 55: Removing A Line Card
Orient the line card cover plate so that the key on the cover plate is at the bottom. See Figure 3-28. Figure 3-28 Line Card Cover Plate Key Line card cover plate key Enterasys K-Series K10 Chassis Hardware Installation Guide 3-29... -
Page 56: Connecting Power
Connecting to the Fabric Card COM Port for Local Management This section describes how to install a UTP cable with RJ45 connectors and optional adapters to connect a PC or VT series terminal to an Enterasys Networks device to access Local Management. This section also details adapter pinout assignments. -
Page 57: Connecting To A Pc Or Laptop
8 Bits, No Parity Stop Bit 1 Stop Bit When these parameters are set, the Local Management password screen will display. Refer to the “Completing the Installation” on page 3-35 for further information. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-31... -
Page 58: Adapter Wiring And Signal Assignments
Link Aggregation to operate properly. Before connecting the cables, refer to the Enterasys K-Series Configuration Guide for the configuration information. For details on how to obtain manuals, refer to “Related... -
Page 59: Connecting Category 5 Utp Ethernet Cables To The Rj45 Ports
Klasse 1. Zur Ansicht der Laserausgabe dürfen keine optischen Geräte verwendet werden, da hierdurch die Wahrscheinlichkeit einer Gefährdung der Augen erhöht wird. Vor der Inspektion des optischen Ausgangsanschlusses muss das Stromkabel des Netzwerkadapters herausgezogen werden. Enterasys K-Series K10 Chassis Hardware Installation Guide 3-33... -
Page 60: Removing A Pluggable Transceiver
Connecting the Fabric Card and Line Card to the Network Caution: Carefully follow the instructions in this manual to avoid damaging the SFP, SFP+, and module. The SFP, SFP+, and module are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. -
Page 61: Connecting To The Fabric Card Usb Port
Completing the Installation of a New System In a K-Series chassis, the installed fabric card is set to the factory default values on chassis power up. A complete list of the factory default values are provided in the Enterasys K-Series Configuration Guide. -
Page 62: First-Time Log-In Using A Console Port Connection
The K-Series chassis is now ready to be configured. For information about setting the IP address and configuring Telnet settings for remote access to K-Series chassis management, refer to the Enterasys K-Series Configuration Guide. The CLI commands enable you to initially set up and perform more involved management configurations. -
Page 63: Completing The Installation Of A K-Series Fabric Card In An Existing Chassis
Management” on page 3-30 to access system management, or use a Telnet connection to access the K-Series fabric card system management as described in the Enterasys K-Series Configuration Guide. Logging in with an Administratively-Configured User Account If the device’s default user account settings have been changed, proceed as follows: At the login prompt, enter your administratively-assigned user name and press ENTER. - Page 64 Completing the Installation 3-38 Chassis Setup...
-
Page 65: Chapter 4: Troubleshooting
The RJ45 ports LEDs on the line cards are in RX/TX mode. You can switch the LED mode by pressing the red POE button next to the POE LED. See Table 4-3 on page 4-4 for RJ45 port indications in RX/TX mode. Enterasys K-Series K10 Chassis Hardware Installation Guide 4-1... -
Page 66: Fabric Card Port Leds
LEDs Table 4-1 Fabric Card LEDs (continued) Color Status None Fan tray is off or booting up. Green All fans in the fan tray are operating normally. Amber One fan in the fan tray has failed. Caution: If a fan in the fan tray fails, you must replace the fan tray as soon as possible to ensure the proper and continued operation of the chassis. -
Page 67: Line Card Port Leds
SFP RX LED for SFP TX LED for SFP+ RX LED bottom port bottom port RJ45 port TX LEDs SFP RX LED for top SFP TX LED for top SFP+ TX LED port port Enterasys K-Series K10 Chassis Hardware Installation Guide 4-3... -
Page 68: Line Card Port Leds (Mini-Rj21)
None Port enabled, but no activity. If you know the port should be (Transmit) active and is not, contact Enterasys Technical Support. Green Flashing. Indicates data transmission None. activity. Flashing frequency indicates the data rate. -
Page 69: Power Supply Leds
Power supply malfunctioning or unplugged DC OK Green Power supply successfully providing 12 VDC to the system Power supply malfunctioning, unplugged, or installed upside down Enterasys K-Series K10 Chassis Hardware Installation Guide 4-5... -
Page 70: Troubleshooting Checklist
Persistent Data Reset, was changed Configuration Guide for the instructions to configure the device. and device name, sometime before either cycling If the problem persists, contact Enterasys Networks for technical etc.) were lost power or pressing the RESET support. when the K10... -
Page 71: Using The Offline/Reset Button
último recurso, puesto que interrumpe todos los procesos del chasis K10 en funcionamiento, lo que podría resultar pérdidas de frames. To reset a K10 chassis without it performing an orderly shutdown routine, press and hold the OFFLINE/RESET button for approximately 6 seconds. Enterasys K-Series K10 Chassis Hardware Installation Guide 4-7... - Page 72 Using the OFFLINE/RESET Button 4-8 Troubleshooting...
-
Page 73: Appendix A: Specifications And Regulatory Compliance
Specifications and Regulatory Compliance This appendix provides operating specifications for the K10 chassis. Enterasys Networks reserves the right to change the specifications at any time without notice. For MTBF information, refer to the following Enterasys Networks support Web site: http://secure.enterasys.com/support/mtbf/... -
Page 74: K-Ac-Ps-1400W
1.56 kg (3.45 lb) Fabric Card Specifications Refer to the data sheet for the specifications of the currently available K-Series fabric cards: http://www.enterasys.com/company/literature/k-ds.pdf Line Card Specifications Refer to the data sheet for the specifications of the currently available K-Series line cards: http://www.enterasys.com/company/literature/k-ds.pdf... -
Page 75: Torque Values
Output Data Carrier Detect (DCD) Output Data Set Ready (DSR) Input Receive Data (RCV) Input Signal Ground (GND) Data Terminal Ready (DTR) Output Request to Send (RTS) Input Clear to Send (CTS) Enterasys K-Series K10 Chassis Hardware Installation Guide A-3... -
Page 76: Regulatory Compliance
Regulatory Compliance Regulatory Compliance This product meets the safety, electromagnetic compatibility (EMC), and environmental requirements listed in Table A-7. Table A-7 Compliance Standards Regulatory Compliance Standard Safety UL 60950-1, FDA 21 CFR 1040.10 and 1040.11, CAN/CSA C22.2 No. 60950-1, EN 60950-1, EN 60825-1, EN 60825-2, IEC 60950-1, 2006/95/EC (Low Voltage Directive) Electromagnetic Compatibility (EMC) FCC 47 CFR Part 15 (Class A), ICES-003 (Class A), EN 55022... -
Page 77: Appendix B: About Poe (Power Over Ethernet)
12.95 to 25.50 watts Proprietary PD Detection K-Series devices support a subset of the currently deployed proprietary PoE methods. This includes support for Cisco PDs, including a proprietary capacitor based detection scheme. Enterasys K-Series K10 Chassis Hardware Installation Guide B-1... -
Page 78: Poe Port Status Leds
If the PoE power needed or requested exceeds the power available, the system will generate a trap to notify the system manager. For more information on configuring allocation mode, see the Enterasys K-Series CLI Reference. Management of PoE Power to PDs You can configure how the K-Series chassis makes power available to attached PDs: •... -
Page 79: Appendix C: Mode Switch Bank Setting And Memory Replacement
Estas modificaciones a la configuración sólo debe realizarlas personal calificado. Figure C-1 on page C-2 shows the location of the mode switches on the fabric card. These switches are set at the factory and rarely need to be changed. Enterasys K-Series K10 Chassis Hardware Installation Guide C-1... -
Page 80: Mode Switch Location On The Fabric Card
Setting the Mode Switches Switch definitions and positions are as follows: • Switches 1–6: For Enterasys Networks use only. • Switch 7: Clear Persistent Data. Changing the position of this switch clears Persistent Data on the next power-up of the module. All user-entered parameters, such as the IP address, system name, and so on, are reset to the factory default settings. -
Page 81: Memory Location And Replacement Procedure
“Getting Help” on page xvii for details on how to contact Enterasys Networks. Before replacing the memory module, you must power down the fabric card and remove it from the K-Series chassis. See “Installing and Removing the Fabric... - Page 82 Memory Location and Replacement Procedure Push down on the assembly to return it to its horizontal position flat on the board. Reinstall the fabric card. C-4 Mode Switch Bank Setting and Memory Replacement...
-
Page 83: Appendix D: Purchasing Mini-Rj21 Cables
Purchasing Mini-RJ21 Cables Enterasys Networks does not supply mini-RJ21 cables for the mini-RJ21 ports on the KT2010-0224 line card. You must purchase mini-RJ21 cables separately. Enterasys Networks has approved Tyco and Belfuse mini-RJ21 cables for use with the KT2010-0224 line card. The following cables types are available: •... -
Page 84: Mini-Rj21 To Mini-Rj21
Mini-RJ21 to Mini-RJ21 Mini-RJ21 to Mini-RJ21 Figure D-1 Mini-RJ21 to Mini-RJ21 The following part numbers are approved: • Tyco: TE 6812553-X • BelFuse: MRJXXXXDD-A Mini-RJ21 Angled to Mini-RJ21 Angled Figure D-2 Mini-RJ21 Angled to Mini-RJ21 Angled The following part numbers are approved: •... -
Page 85: Mini-Rj21 To Rj45
The following part numbers are approved: • Tyco: TE 6837058-X • BelFuse: MRJXXXXDF-A Mini-RJ21 to RJ45 Figure D-4 Mini-RJ21 to RJ45 The following part numbers are approved: • Tyco: TE 1499520-X • BelFuse: MRJXXXXAD-A Enterasys K-Series K10 Chassis Hardware Installation Guide D-3... -
Page 86: Mini-Rj21 Angled To Rj45
Mini-RJ21 Angled to RJ45 Mini-RJ21 Angled to RJ45 Figure D-5 Mini-RJ21 Angled to RJ45 The following part numbers are approved: • Tyco: TE 6713358-X • BelFuse: MRJXXXXAF-A Distributors For more information about purchasing mini-RJ21 cables, contact a Tyco or Belfuse distributor. •... -
Page 87: Appendix E: Environmental Guidelines
This is not necessarily the same air temperature throughout the room. Cooling Air Many Enterasys switches utilize a side to side airflow method for cooling. Careful consideration is needed when mounting this equipment. Proper inlet and exit spaces must be allowed to get fresh, cool air into the equipment and to allow hot exhaust air to exit away from the equipment. -
Page 88: Airflow Concerns For Closed Racks
Temperature and Humidity Guidelines Airflow Concerns for Closed Racks When placing Enterasys switches into enclosed racks, rack exhaust fans must be considered if the rack does not contain adequate inlet and exit venting. These fans may be needed to help exhaust hot air from the rack. -
Page 89: Airflow Concerns For Open Racks
E-4 below shows a non-ideal configuration for an open rack, where sub- systems with mixed flow directions (white arrows) are combined in one rack. Circular red arrows show potential for hot air recirculation. Enterasys K-Series K10 Chassis Hardware Installation Guide E-3... -
Page 90: Non-Ideal Open Rack Configuration
Temperature and Humidity Guidelines Figure E-3 Non-ideal Open Rack Configuration Non-ideal flows should be avoided or mitigated and confirmed through thermal testing. Figure E-4 below shows a non-ideal open rack configuration containing sub-systems with mixed flow directions (white arrows). This configuration shows mitigation of potential hot air recirculation by leaving a gap in the rack population. -
Page 91: Dust Mitigation And Prevention
Dust accumulation on inlet and exit venting is not uncommon after prolonged use. In dustier environments this accumulation can be much quicker. Enterasys strongly recommends routine maintenance to check for clean inlet and exit vents on this equipment. Over time, dust accumulation can create vent blockages, thereby decreasing airflow and increasing component temperatures, resulting in reduced reliability. -
Page 92: Airborne Chemicals And Prevention
Airborne Chemicals and Prevention Table E-1 Airborne Dust Specification for Enterasys Equipment — Airborne Dust Maximum Values Dust Guidelines All/Total Airborne Particles (TSP-Dichot 15): 20 µg/m PM10/Coarse Particles (2.5 to 15 microns): Preferred : <10 µg/m Maximum : 20 µg/m PM2.5/Fine particles (< 2.5 microns): 10 µg/m...
