Introduction; Overview - Enterasys Matrix N3 7C103 Hardware Installation Manual

This chapter provides an overview of the Matrix N3 7C103 Chassis and its features. Also covered
in this chapter are the instructions on how to obtain additional help from Enterasys Networks™ if
needed.
1.1

OVERVIEW

The N3 chassis provides three slots that can contain a variety of modules. The chassis backplane
supports a new generation of advanced switching modules (7Hxxxx and 7Gxxxx series).
The N3 chassis
•
uses a distributed switching architecture,
•
allows hot swapping of the modules, and fan assembly,
•
supports redundant power supplies, and
•
can be installed as a freestanding chassis or installed into a standard 48.26-centimeter (19-inch)
rack, occupying only 36 centimeters (14 inches) of vertical rack space.
The power supplies and modules are installed from the front of the chassis for ease of
maintenance. Removal and re-installation of the fan assembly is from the rear of the chassis. All
LED indicators are observable from the front of the chassis to aid in monitoring network
operational status and performing maintenance.
three modules and two 7C203-1 redundant power supplies.
Figure 1-1 illustrates the chassis equipped with
