3. Specifications
There are currently four different models of NB1600 available:
• NB1600 Mobile
• NB1600 Mobile & WLAN
• NB1600 WLAN
• NB1600 Wireline

3.1. Operating Elements

The following table describes the router's status indicators. The color of the LED
represents the signal quality for wireless links.
red means low
yellow means moderate
green means good or excellent
Label Color
Status blinking The device is busy due to startup, software or configu-
PPPoE
Mobile
blinking Mobile connection is being established.
VPN
WLAN
blinking WLAN connection is being established.
State Function
ration update.
on The device is ready. The captions of the right bank
apply.
on The device is ready. The captions of the left bank apply.
on PPPoE connection is up.
off PPPoE connection is down.
on Mobile connection is up.
off Mobile connection is down.
on VPN connection is up.
off VPN connection is down.
on WLAN connection is up.
