Switching Pages; Port Configuration - HP ProCurve 1810G Management And Configuration Manual

Switching Pages

You can use the Switching Pages to configure port operation and capabilities.

Port Configuration

Use the Port Configuration page to view and configure parameters for port operation. To access this
page, click
Figure 4-1. Port Configuration Page
Note
The display and the content of this page changes based on the physical port selected. For example, if
the selected port is an optional copper/fiber port and fiber is being used, than the Link Speed selections
will display only valid options for that port.
Table 4-1. Port Configuration Fields
Switching > Port Configuration
Field Description
Interface Select the interface to configure.
Physical Type Describes the port type (i.e., Copper or Fiber).
Link Status Displays Up or Down to indicate operational status.
Admin Mode Select to enable access to the port on the network. Clear to disable the port.
in the navigation pane.
4
4-1
