Interface Layout and Features

Figure 1-2 shows the initial view.
Figure 1-2. Interface Layout and Features
Navigation Pane
Click on any topic in the navigation page to display related configuration options.
The System Description page displays when you first log on and when you click Home or Status > System
Description in the navigation pane. See
You can click the Setup Network link beneath Home to display the Get Connected page, which you use
to set up a management connection to the switch. You can also click Network Setup > Get Connected to
display this page. See
The Web Applet displays summary information for the switch LEDs and port status in a graphical
format. For information on the Web Applet, see

Common Page Elements

■ Click on each page to display a help panel that explains the fields and configuration
options on the page.
■ Click to send the updated configuration to the switch. Configuration changes take
effect immediately, but some changes are not retained across a power cycle unless the changes
are saved to the system configuration file.
Web Applet
"System Description" on page 2-1
"Get Connected" on page 3-1
Getting Started With the Web Interface
for more information.
"Web Applet" on page 1-4.
Getting Started
Common Links
for more information.
1-3
