TASCAM TDIF
The TASCAM TDIF daughter card offers 24 channels of I/O over 3 Tascam TDIF connections. Connection is via three
DB-25 connectors, One on the main card attached to the Mykerinos and two more on a separate bracket con-
nected via internal ribbon cable to the main card.
TASCAM TDIF I/O Option
A TASCAM TDIF format option bracket may be added to the ADAT I/O daughtercard and provides is available for 8
channels of TDIF I/O. The TDIF bracket connects to a socket on the ADAT card only. This daughter card cannot be
used in multi-board systems (since it utilizes the HTDM connector).

Daughter Card Support in Pyramix 8 MassCore

Daughter Cards
MADI-I
MADI-II
ADAT (Serials
20000 to 20299)
ADAT (Serials
20300 and +)
AES-I
AES-II
SDIF
TDIF
DUAL
Note 1: Full i/o of ADAT and SPDIF supporte d
Note 2: 16 ADAT i/o supported. No SPDIF i/o.
Standalone-Mono-board
MassCore & Non-Masscore &
Pm x 6.x
?
?
?
? (Note1)
?
?
?
?
?
Appendices : Appendix II Legacy Mykerinos I/O Daughter-card Options
MassCore &
Pm x 6.x Pmx 6.x
? Not Supporte d
? ?
? Not Supporte d
? (Note1) ? (Note 2)
? ?
? ?
? ?
? ?
? ?
Multi-board
Non-MassCore &
Pmx 6.x
Not Supported
?
Not Supported
?
?
?
?
?
Not Supported
30 - 730
