Background Recorder Transport Control Panel
Clicking on the title bar toggles the panel between collapsed and full. When pre-buffering is active the amount of
memory used is shown in the title bar.
Upper Section of Panel
For detailed information on the upper section of the panel please see: Internal / External Machine panels -
Features on page 506
Controls
Toggles the Mixer window associated with the Background Recorder open/closed.
Toggles the Monitor source between the Pyramix Timeline Mixer and the Background
Recorder Mixer. Lights yellow when Monitor source is the Background Recorder.
Opens Pyramix Settings on the Background Recorders page.
Starts Recording.
Stop - One press Stops the recording but leaves the Recorder Enabled.
Enables the Recorder.
Enables/disables Chase. Lights blue when Chase is enabled.
Opens a floating Media Management Window showing the recordings.
Ctrl Control, lights orange when active. Pressing Ctrl or selecting it in the Transport Toolbar
combo box routes keyboard shortcuts, Sony 9-Pin commands or controllers to the Back-
ground Recorder.
Notes
• Each recorder acts as an independent machine like the Internal or any External Machine.
• Background Recorders are started and stopped manually from the Transport Window.
• When set to Chase Background Recorders follow the current Master.
Recording and Acquisition : Background Recorders
Background Recorder Transport Control Panel
7 - 146
